VLT® Flow Drive FC 111
Programming Guide
Parameter Option
0.000–1000.000 mH
Parameter 1-38
q-axis Induc-
tance (Lq)
Parameter 1-39 2–100
Motor Poles
Parameter 1-40 10–9000 V
Back EMF at
1000 RPM
0–100 m
Parameter 1-42
Motor Cable
Length
Parameter 1-44 0.000–1000.000 mH
d-axis Induc-
tance Sat.
(LdSat)
0.000–1000.000 mH
Parameter 1-45
q-axis Induc-
tance Sat.
(LqSat)
20–200%
Parameter 1-46
Position Detec-
tion Gain
Parameter 1-48 20–200%
Current at Min
Inductance for
d-axis
Parameter 1-49 20–200%
Current at Min
Inductance for
q-axis
Parameter 1-70
[0] Rotor Detection
PM Start Mode
[1] Parking
[3] Rotor Last Position
Parameter 1-73
[0] Disabled
Flying Start
[1] Enabled
-4999.000–4999.000
Parameter 3-02
Minimum Refer-
ence
Parameter 3-03 -4999.000–4999.000
Maximum Ref-
erence
Danfoss A/S © 2021.07
Default Usage
Size related Enter the value of the q-axis inductance.
4 Enter the number of motor poles.
Size related Line-line RMS back EMF voltage at 1000 RPM.
Enter the motor cable length.
50 m
Size related This parameter corresponds to the inductance saturation of
Ld. Ideally, this parameter has the same value as parameter
1-37 d-axis Inductance (Ld). However, if the motor supplier
provides an induction curve, enter the induction value,
which is 200% of the nominal current.
Size related This parameter corresponds to the inductance saturation of
Lq. Ideally, this parameter has the same value as parameter
1-38 q-axis Inductance (Lq). However, if the motor supplier
provides an induction curve, enter the induction value,
which is 200% of the nominal current.
Adjusts the height of the test pulse during position detec-
100%
tion at start.
100% Enter the inductance saturation point.
100% This parameter specifies the saturation curve of the d- and q-
inductance values. From 20–100% of this parameter, the in-
ductances are linearly approximated due to parameter 1-37
d-axis Inductance (Ld), parameter 1-38 q-axis Inductance (Lq),
parameter 1-44 d-axis Inductance Sat. (LdSat), and parameter
1-45 q-axis Inductance Sat. (LqSat).
[1] Parking Select the PM motor start mode.
[0] Disabled Select [1] Enabled to enable the drive to catch a motor spin-
ning due to mains drop-out. Select [0] Disabled if this func-
tion is not required. When this parameter is set to [1] Ena-
bled, parameter 1-71 Start Delay and parameter 1-72 Start
Function are not functional. Parameter 1-73 Flying Start is ac-
+
tive in VVC
The minimum reference is the lowest value obtainable by
0
summing all references.
50 The maximum reference is the lowest obtainable by sum-
ming all references.
mode only.
