VLT® Flow Drive FC 111
Programming Guide
[5]
[6]
[7]
[8]
13-44 Logic Rule Boolean 3
Default value: [0] False
Conversion index: -
rd
Select the 3 boolean (True or False) input for the selected logic rule.
Table 230: Option:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
Danfoss A/S © 2021.07
NOT AND
NOT OR
NOT AND NOT
NOT OR NOT
Parameter type: Option
Data type: u_int8
Enter the fixed value of False in the logic rule.
Enter the fixed value True in the logic rule.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
See parameter 13-01 Start Event for further description.
Use the result of comparator 0 in the logic rule.
Use the result of comparator 1 in the logic rule.
Use the result of comparator 2 in the logic rule.
Use the result of comparator 3 in the logic rule.
Use the result of logic rule 0 in the logic rule.
Use the result of logic rule 1 in the logic rule.
Use the result of logic rule 2 in the logic rule.
Use the result of logic rule 3 in the logic rule.
Use the result of timer 0 in the logic rule.
Use the result of timer 1 in the logic rule.
2-setup: 1 setup
Change during operation: True
AU363928304090en-000101 / 130R0982 | 125
