Extended Status Words - Danfoss VLT Flow Drive FC 111 Programming Manual

VLT® Flow Drive FC 111
Programming Guide
Bit Hex Dec
13 2000 8192
14 4000 16384
15 8000 32768
16 10000 65536
17 20000 131072
18 40000 262144
19 80000 524288
20 100000 1048576
21 200000 2097152
22 400000 4194304
23 800000 8388608
24 1000000 16777216
25 2000000 33554432
26 4000000 67108864
27 8000000 134217728
28 10000000 268435456
29 20000000 536870912
30 40000000 1073741824
31 80000000 2147483648
Note that 0 in the table indicates that this status word is not supported.

5.4 Extended Status Words

Table 473: Extended Status Words
Bit Hex Dec
0 1 1
1 2 2
2 4 4
3 8 8
4 10 16
5 20 32
6 40 64
7 80 128
8 100 256
Danfoss A/S © 2021.07
Parameter 16-92 Warning Word
0
Mains ph. loss
No motor
Live zero error
0
0
0
0
0
0
24 V supply low
0
Current limit
Low temp.
0
0
0
0
0
Parameter 16-94 Ext. Status Word
Ramping
AMA running
Start CW/CCW
0
0
Feedback high
Feedback low
Output current high
Output current low
Troubleshooting
Parameter 16-93 Warning Word 2
0
0
Auto DC braking
0
0
Fans warning
0
0
0
Memory module
0
0
0
0
0
0
Back-EMF too high
0
0
Parameter 16-95 Ext. Status Word 2
Off
Hand/Auto
0
0
0
0
0
Control ready
Drive ready
