VLT® Flow Drive FC 111
Programming Guide
[3]
Drive ready/remote
control
[4]
Standby/no warning
[5]
Drive running
[6]
Running/no warning
[7]
Run in range/no warn-
ing
[8]
Run on ref/no warning
[9]
Alarm
[10]
Alarm or warning
[12]
Out of current range
[13]
Below current, low
[14]
Above current, high
[16]
Below speed, low
[17]
Above speed, high
[19]
Below feedback, low
[20]
Above feedback, high
[21]
Thermal warning
[22]
Ready, no thermal
warning
[23]
Remote, ready, no
thermal warning
[24]
Ready, Voltage OK
[25]
Reverse
[26]
Bus OK
[35]
External Interlock
[36]
Control word bit 11
[37]
Control word bit 12
[41]
Below reference, low
[42]
Above ref, high
[45]
Bus Control
[60]
Comparator 0
Danfoss A/S © 2021.07
The drive is ready for operation in auto-on mode.
The drive is ready for operation. No start or stop command is given. No warnings are present.
The motor runs.
The motor runs, and no warnings are present.
The motor runs within the programmed current ranges, see parameter 4-50 Warning Current
Low and parameter 4-51 Warning Current High. No warnings are present.
The motor runs at reference speed and with no warnings.
An alarm activates output.
An alarm or warning activates output.
The motor current is outside the ranges set in parameter 4-50 Warning Current Low and parame-
ter 4-51 Warning Current High.
The motor current is lower than the limit set in parameter 4-50 Warning Current Low.
The motor current is higher than the limit set in parameter 4-51 Warning Current High.
The drive output speed is lower than the limit set in parameter 4-40 Warning Freq. Low.
The drive output speed is higher than the limit set in parameter 4-41 Warning Freq. High.
The feedback is lower than the limit set in parameter 4-56 Warning Feedback Low.
The feedback is higher than the limit set in parameter 4-57 Warning Feedback High.
The thermal warning turns on when the temperature exceeds the limit in motor, drive, or ther-
mistor.
The drive is ready for operation and no thermal warning is present.
The drive is ready for operation in auto mode, and no thermal warning is present.
The drive is ready for operation and mains voltage is within the specified voltage range.
The motor runs/is ready to run clockwise when logic = 0 and counterclockwise when logic = 1.
Output changes as soon as reversing signal is applied.
Active communication (no timeout) via serial communication port.
See [7] External Interlock in the parameter group 5-1* Digital Input.
Bit 11 in control word controls the relay.
Bit 12 in control word controls the relay.
The reference is lower than the limit set in parameter 4-54 Warning Reference Low.
The reference is higher than the limit set in parameter 4-55 Warning Reference High.
The output is configured in parameter 5-90 Digital & Relay Bus Control.
See parameter group 13-1* Comparators. If comparator 0 is evaluated as true, the output goes
high. Otherwise, it is low.
Parameters
