VLT® Flow Drive FC 111
Programming Guide
16-37 Inv. Max. Current
Default value: 0 A
Conversion index: -2
View the inverter maximum current. The data is used for calculation of drive protection and so on.
Table 318: Range:
Min: 0 A
The maximum display value is 655.35 A, if the actual drive inverter maximum current surpasses 655.35 A, the data can be viewed
from parameter 18-87 Inv. Max. Current.
16-38 SL Controller State
Default value: 0
Conversion index: 0
View the actual state of the smart logic controller (SLC).
Table 319: Range:
Min: 0
4.13.4 16-5* Ref. & Feedb.
16-50 External Reference
Default value: 0%
Conversion index: -1
View the total reference, the sum of digital, analog, preset, bus, and freeze references.
Table 320: Range:
Min: -200%
16-52 Feedback[Unit]
Default value: 0 ProcessCtrlUnit
Conversion index: -3
View the feedback resulting from the selection of scaling in parameter 3-02 Minimum Reference and parameter 3-03 Maximum Refer-
ence.
Table 321: Range:
Min: -4999 Max: 4999 ProcessCtrlUnit
16-54 Feedback 1 [Unit]
Default value: 0 ProcessCtrlUnit
Conversion index: -3
View the feedback 1 value resulting from the selection of scaling in parameter 3-02 Minimum Reference and parameter 3-03 Maxi-
mum Reference and selection of unit in parameter 20-12 Reference/Feedback Unit.
150 | Danfoss A/S © 2021.07
Parameter type: Range
Data type: u_int16
Max: 655.35 A
N O T I C E
Parameter type: Range
Data type: u_int8
Max: 20
Parameter type: Range
Data type: int16
Max: 200%
Parameter type: Range
Data type: int32
Parameter type: Range
Data type: int32
2-setup: 1 setup
Change during operation: True
Default value: 0 A
2-setup: 1 setup
Change during operation: True
Default value: 0
2-setup: 1 setup
Change during operation: True
Default value: 0%
2-setup: 1 setup
Change during operation: True
Default value: 0 ProcessCtrlUnit
2-setup: All setups
Change during operation: True
AU363928304090en-000101 / 130R0982
