VLT® FC 100 LonWorks
9.1.3 War ning w or ds
Warning Word
Warning w or d , par . 16-92
Bit
( Hex )
00000001
00000002
00000004
00000008
00000010
00000020
00000040
00000080
00000100
00000200
00000400
00000800
00001000
00002000
00004000
00008000
00010000
00020000
00040000
00080000
00100000
00200000
00400000
00800000
01000000
02000000
04000000
08000000
10000000
20000000
40000000
80000000
Warning Wor d
( par. 16- 92 Warning Word )
Brake check
Power card over temperature
Earth fault
Ctrl. card over temperature
Control word timeout
Over current
Torque limit
Motor thermistor over temp.
Motor ETR over temperature
Inverter overloaded
DC link under voltage
DC link over voltage
DC link voltage low
DC link voltage high
Mains phase loss
No motor
Live zero error
10V low
Brake resistor power limit
Brake resistor short circuit
Brake chopper fault
Speed limit
Fieldbus comm. fault
24V supply fault
Mains failure
Current limit
Low temperature
Voltage limit
Encoder loss
Output frequency limit
Not used
Not used
®
MG.11.E2.02 - VLT is a registered Danfoss trademark
Warning Word 2
War ning w ord 2, par . 16-93
Bit
( Hex )
00000001
00000002
00000004
00000008
00000010
00000020
00000040
00000080
00000100
00000200
00000400
00000800
00001000
00002000
00004000
00008000
00010000
00020000
00040000
00080000
00100000
00200000
00400000
00800000
01000000
02000000
04000000
08000000
10000000
20000000
40000000
80000000
9 Troubleshooting
War ning Word 2
( par . 16-93 Warning Word
2 )
Start Delayed
Stop Delayed
Clock Failure
Reserved
Reserved
No Flow
Dry Pump
End of Curve
Broken Belt
Not used
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Not used
Fans warning
ECB warning
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
