VLT® Flow Drive FC 111
Programming Guide
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-41 Logic Rule Operator 1
Default value: [0] Disabled
Conversion index: -
Table 227: Option:
[0]
[1]
[2]
122 | Danfoss A/S © 2021.07
Use the result of logic rule 2 in the logic rule.
Use the result of logic rule 3 in the logic rule.
Use the result of timer 0 in the logic rule.
Use the result of timer 1 in the logic rule.
Use the result of timer 2 in the logic rule.
Use the value of DI18 in the logic rule (High = True).
Use the value of DI19 in the logic rule (High = True).
Use the value of DI27 in the logic rule (High = True).
Use the value of DI29 in the logic rule (High = True).
This logic rule is True if the drive is started by any means (either via digital input, or other).
This logic rule is True if the drive is stopped or coasted by any means (either via digital input, or
other).
This logic rule is True if the drive is tripped (but not trip-locked) and an automatic reset is issued.
Use the result of comparator 4 in the logic rule.
Use the result of comparator 5 in the logic rule.
Use the result of logic rule 4 in the logic rule.
Use the result of logic rule 5 in the logic rule.
Use the result of timer 3 in the logic rule.
Use the result of timer 4 in the logic rule.
Use the result of timer 5 in the logic rule.
Use the result of timer 6 in the logic rule.
Use the result of timer 7 in the logic rule.
A dry-pump condition has been detected. Enable this function in parameter 22-26 Dry Pump Func-
tion.
An end-of-curve condition has been detected. Enable this function in parameter 22-50 End of Curve
Function
A broken-belt condition has been detected. Enable this function in parameter 22-60 Broken Belt
Function.
Parameter type: Option
Data type: u_int8
Disabled
AND
OR
2-setup: 1 setup
Change during operation: True
AU363928304090en-000101 / 130R0982
Parameters
