Table 291: Range:
Min: 0
15-97 Application Type
Default value: 0
Conversion index: 0
This parameter contains data used by the MCT10 software tool.
Table 292: Range:
Min: 0 Max: 4294967295
15-98 Drive Identification
Default value: 0
Conversion index: 0
This parameter contains data used by the MCT10 software tool.
Table 293: Range:
Min: 0

4.13 Parameter Group 16-** Data Readouts

4.13.1 16-0* General Status
Parameters for reading the general status, for example, the calculated reference, the active control word, and status.
16-00 Control Word
Default value: 0
Conversion index: 0
View the control word sent from the drive via the serial communication port in hex code.
Table 294: Control Word
Bit Bit=0
00 Preset reference option lsb
01 Preset reference option 2
02 DC brake
03 Coasting
04 Quick stop
05 Freeze output
06 Ramp stop
07 No function
08 No function
09 Ramp 1
10 Data not valid
144 | Danfoss A/S © 2021.07
Max: 2000
Parameter type: Range
Data type: u_int32
Parameter type: Range
Data type: VisibleString
Max: 56
Parameter type: Range
Data type: u_int16
nd
bit of preset references
Default value: 0
2-setup: 1 setup
Change during operation: True
Default value: 0
2-setup: 1 setup
Change during operation: False
Default value: 0
2-setup: 1 setup
Change during operation: True
AU363928304090en-000101 / 130R0982
Parameters
Bit=1
–
–
Ramp
Enable
Ramp
Ramp
Start
Reset
Jog
Ramp 2
Valid
