VLT® Flow Drive FC 111
Programming Guide
Bit Bit=0
07 No warning
08 Speed ≠ ref.
09 Local control
10 Out of range
11 Not running
12 No function
13 Voltage OK
14 Current OK
15 Thermal-level OK
Table 299: Range:
Min: 0
16-05 Main Actual Value [%]
Default value: 0%
Conversion index: -2
View the 2 byte word sent with the status word to the bus master reporting the main actual value.
Table 300: Range:
Min: -200%
16-09 Custom Readout
Default value: 0 CustomReadoutUnit
Conversion index: -2
View the user-defined readouts as defined in parameter 0-30 Custom Readout Unit, parameter 0-31 Custom Readout Min Value, and
parameter 0-32 Custom Readout Max Value.
Table 301: Range:
Min: 0 Max: 9999 CustomReadoutUnit
4.13.2 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Default value: 0 kW
Conversion index: -3
Display the actual motor power in kW. The value shown is calculated on the basis of the actual DC-link voltage and DC-link current.
Table 302: Range:
Min: 0 kW
146 | Danfoss A/S © 2021.07
Max: 65535
Parameter type: Range
Data type: int16
Max: 200%
Parameter type: Range
Data type: int32
Parameter type: Range
Data type: u_int32
Max: 1000 kW
Bit=1
Warning
Speed = ref.
Bus control
Frequency OK
Running
No function
Above limit
Above limit
Above limit
Default value: 0
2-setup: 1 setup
Change during operation: True
Default value: 0%
2-setup: 1 setup
Change during operation: True
Default value: 0 CustomReadoutUnit
2-setup: 1 setup
Change during operation: True
Default value: 0 kW
AU363928304090en-000101 / 130R0982
Parameters
