[21] Thermal warning
[22] Ready, no thermal
warning
[23] Remote, ready, no
thermal warning
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[35] External Interlock
[36] Control word bit 11
[37] Control word bit 12
[41] Below reference, low
[42] Above ref, high
[45] Bus Control
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
Danfoss A/S © 2021.07
The thermal warning turns on when the temperature exceeds the limit in motor, drive, or ther-
mistor.
The drive is ready for operation and no thermal warning is present.
The drive is ready for operation in auto-on mode, and no thermal warning is present.
The drive is ready for operation and mains voltage is within the specified voltage range.
The motor runs/is ready to run clockwise when logic = 0 and counterclockwise when logic = 1.
Output changes as soon as reversing signal is applied.
Active communication (no timeout) via serial communication port.
See digital input.
Bit 11 in control word controls the relay.
Bit 12 in control word controls the relay.
The reference is lower than the limit set in parameter 4-54 Warning Reference Low.
The reference is higher than the limit set in parameter 4-55 Warning Reference High.
The output is configured in parameter 5-90 Digital & Relay Bus Control.
See parameter group 13-1* Comparators. If comparator 0 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 1 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 2 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 3 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 4 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 5 is evaluated as true, the output goes
high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 0 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 1 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 2 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 3 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 4 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 5 is evaluated as true, the output goes high.
Otherwise, it is low.
