VLT® Flow Drive FC 111
Programming Guide
Table 176: Option:
[0]
[1]
[2]
6-91 Terminal 42 Analog Output
Default value: [0] No operation
Conversion index: -
Select the function of terminal 42 as an analog current output. See also parameter 6-90 Terminal 42 Mode.
Table 177: Option:
[0]
[100]
[101]
[102]
[103]
[106]
[139]
[184]
[185]
[254]
6-92 Terminal 42 Digital Output
Default value: [0] No operation
Conversion index: -
Select the function of terminal 42 as a digital current output. See also parameter 6-90 Terminal 42 Mode. See parameter 5-40 Function
Relay for description of the options.
Table 178: Option:
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready/remote control
[4] Standby/no warning
[5] Drive running
[6] Running/no warning
[7] Run in range/no warning
[8] Run on ref/no warning
100 | Danfoss A/S © 2021.07
0-20 mA
4-20 mA
Digital Output
Parameter type: Option
Data type: u_int8
No operation
Output frequency
Reference
Feedback
Motor current
Power
Bus control
Mirror AI53 mA
Mirror AI54 mA
DC link voltage
Parameter type: Option
Data type: u_int8
2-setup: All setups
Change during operation: True
2-setup: All setups
Change during operation: True
AU363928304090en-000101 / 130R0982
Parameters
