Danfoss VLT Flow Drive FC 111 Programming Manual page 82

VLT® Flow Drive FC 111
Programming Guide
[168] Drive in hand mode
[169] Drive in auto mode
[188] AHF Capacitor Con-
nect
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt Function
[196] Fire Mode
[198] Drive Bypass
[200] Full capacity
[201] Pump 1 running
[202] Pump 2 running
[203] Pump 3 running
[204] Pump 4 running
[205] Pump 5 running
[211] Cascade Pump 1
[212] Cascade Pump 2
[213] Cascade Pump 3
[214] Cascade Pump 4
[215] Cascade Pump 5
5-31 Terminal 29 Digital Output
Default value: [0] No operation
Conversion index: -
Select the function for terminal 29 digital output.
Table 139: Option:
[0] No operation
[1] Control Ready
[2] Drive ready
82 | Danfoss A/S © 2021.07
The output is high when the drive is in hand-on mode (as indicated by the LED light above
[Hand On]).
The output is high when the drive is in auto-on mode (as indicated by the LED light above [Auto
On]).
Connect or disconnect AHF capacitor.
A no-flow condition has been detected. See parameter group 22-2* No-Flow Detection.
A dry-pump condition has been detected. Enable the function in parameter 22-26 Dry Pump
Function.
An end-of-curve condition has been detected. Enable the function in parameter 22-50 End of
Curve Function.
The drive/system has entered sleep mode. See parameter group 22-4* Sleep Mode.
A broken-belt condition has been detected. Enable the function in parameter 22-60 Broken Belt
Function.
The drive is operating in fire mode. See parameter group 24-0* Fire Mode.
To be used as a signal for activating an external electromechanical bypass, switching the motor
directly on line. See parameter group 24-1* Drive Bypass.
The drive enters full capacity mode.
Pump 1 is running.
Pump 2 is running.
Pump 3 is running.
Pump 4 is running.
Pump 5 is running.
Cascade pump 1 is running.
Cascade pump 2 is running.
Cascade pump 3 is running.
Cascade pump 4 is running.
Cascade pump 5 is running.
Parameter type: Option
Data type: u_int8
No operation.
The control board receives supply voltage.
The drive is ready for operation and applies a supply signal on the control board.
2-setup: All setups
Change during operation: True
AU363928304090en-000101 / 130R0982
Parameters
