[5] DC-brake in- Inverted input for DC braking (NC). Stops the motor by energizing it with DC current for a certain time
verse period, see parameter 2-01 DC Brake Current. The function is only active when the value in parameter
2-02 DC Braking Time is different from 0. This selection is not possible when parameter 1-10 Motor Con-
struction is set to [1] PM non-salient SPM.
[6] Stop inverse The stop inverse function generates the stop function when the selected terminal goes from logical
level 1 to 0 (not latched). Stop is performed according to selected ramp time.
[7] External Inter- Same function as coast stop, inverse, but external interlock generates the alarm message external fault
lock on the display when the terminal programmed for coast inverse is logic 0. If programmed for external
interlock, the alarm message is also active via digital outputs and relay outputs. If the cause for the
external interlock is removed, the alarm can be reset using a digital input, fieldbus, or the [Reset] key.
[8] Start Select start for a start/stop command. Logic 1 = start, logic 0 = stop. (Default digital input 18).
[9] Latched start If a pulse is applied for a minimum of 2 ms, the motor starts. The motor stops when stop inverse is
activated.
[10] Reversing Change direction of motor shaft rotation. The reversing signal only changes the direction of rotation, it
does not activate the start function. Select [2] Both directions in parameter 4-10 Motor Speed Direction. 0
= normal, 1 = reversing.
[11] Start reversing
Use for start/stop and for reversing at the same time. Signals on [8] Start are not allowed at the same
time. 0 = stop, 1 = start reversing.
[14] Jog Used for activating jog speed. See parameter 3-11 Jog Speed [Hz]. (Default digital input 29).
[16] Preset ref bit 0 Enable a selection of 1 of the 8 preset references according to
[17] Preset ref bit 1 Enable a selection of 1 of the 8 preset references according to
[18] Preset ref bit 2 Enable a selection of 1 of the 8 preset references according to
[19] Freeze refer- Freeze actual reference. The frozen reference is now the point of enable/condition for speed up and
ence speed down to be used. If speed up/speed down is used, a speed change always follows ramp 2 (pa-
rameter 3-51 Ramp 2 Ramp Up Time and parameter 3-52 Ramp 2 Ramp Down Time) in the range parame-
ter 3-02 Minimum Reference - parameter 3-03 Maximum Reference.
[20] Freeze output Freezes actual reference. The frozen reference is now the point of enable/condition for speed up and
speed down to be used. If speed up/speed down is used, the speed change always follows ramp 2.
[21] Speed up For digital control of the up/down speed (motor potentiometer). Activate this function by selecting
either freeze reference or freeze output. When speed up is activated for less than 400 ms, the resulting
reference is increased by 0.1%. If speed up is activated for more than 400 ms, the resulting reference
ramps according to ramp 1 in parameter 3-41 Ramp 1 Ramp Up Time.
[22] Speed down Same as [21] Speed up, but reference decreases.
[23] Set-up select Selects 1 of the 2 setups. Set parameter 0-10 Active Set-up to multi setup.
bit 0
[34] Ramp bit 0 Select which ramp to use. Logic 0 selects ramp 1, while logic 1 selects ramp 2.
[37] Fire Mode A signal applied puts the into fire mode and disregards all other commands. See parameter group 24-0*
Fire Mode.
[52] Run permissive The input terminal, for which the run permissive is programmed, must be logic 1 before a start com-
mand can be accepted. Run permissive has a logic AND function related to the terminal, which is pro-
grammed for [8] Start, [14] Jog, or [20] Freeze Output. To start running the motor, both conditions must
be fulfilled. If run permissive is programmed on multiple terminals, run permissive only has to be logic
1 on 1 of the terminals for the function to be carried out. Run permissive does not affect the digital
output signal for run request ([8] Start, [14] Jog, or [20] Freeze Output) programmed in parameter group
5-3* Digital Outputs, or parameter group 5-4* Relays.
