[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
118 | Danfoss A/S © 2021.07
See parameter 13-01 Start Event for further description.
Use the result of comparator 0 in the logic rule.
Use the result of comparator 1 in the logic rule.
Use the result of comparator 2 in the logic rule.
Use the result of comparator 3 in the logic rule.
Use the result of logic rule 0 in the logic rule.
Use the result of logic rule 1 in the logic rule.
Use the result of logic rule 2 in the logic rule.
Use the result of logic rule 3 in the logic rule.
Use the result of timer 0 in the logic rule.
Use the result of timer 1 in the logic rule.
Use the result of timer 2 in the logic rule.
Use the value of DI18 in the logic rule (High = True).
Use the value of DI19 in the logic rule (High = True).
Use the value of DI27 in the logic rule (High = True).
Use the value of DI29 in the logic rule (High = True).
This event is True if the drive is started by any means (either via digital input, or other).
This event is True if the drive is stopped or coasted by any means (either via digital input, or other).
This event is True if the drive is tripped (but not trip-locked) and an automatic reset is issued.
Use the result of comparator 4 in the logic rule.
Use the result of comparator 5 in the logic rule.
Use the result of logic rule 4 in the logic rule.
Use the result of logic rule 5 in the logic rule.
Use the result of timer 3 in the logic rule.
Use the result of timer 4 in the logic rule.
Use the result of timer 5 in the logic rule.
Use the result of timer 6 in the logic rule.
Use the result of timer 7 in the logic rule.
A dry-pump condition has been detected. Enable this function in parameter 22-26 Dry Pump Func-
tion.
An end-of-curve condition has been detected. Enable this function in parameter 22-50 End of Curve
Function
A broken-belt condition has been detected. Enable this function in parameter 22-60 Broken Belt
Function.
