6.2 Definitions

6.2.1 AC Drive

Coast
The motor shaft is in free mode. No torque on the motor.
I
VLT,MAX
Maximum output current.
I
VLT,N
Rated output current supplied by the drive.
U
VLT,MAX
Maximum output voltage.

6.2.2 Input

Control commands
Start and stop the connected motor with LCP and digital inputs.
Functions are divided into 2 groups.
Functions in group 1 have higher priority than functions in group 2.
Table 475: Function Groups
Group 1
Reset, coast stop, reset and coast stop, quick stop, DC brake, stop, and [Off].
Group 2
Start, pulse start, reversing, start reversing, jog, and freeze output.

6.2.3 Motor

Motor running
Torque generated on the output shaft and speed from 0 RPM to maximum speed on the motor.
f
JOG
Motor frequency when the jog function is activated (via digital terminals or bus).
f
M
Motor frequency.
f
MAX
Maximum motor frequency.
f
MIN
Minimum motor frequency.
f
M,N
206 | Danfoss A/S © 2021.07
Nominal motor power
Protective extra low voltage
Printed circuit board
Permanent magnet motor
Regenerative terminals
Revolutions per minute
Second
Torque limit
Nominal motor voltage
Volts
