Enclosure and Component Installation
Physical connections to the components
Table 3-2. Connectors for modules in the COP slot
Connector Function
PCMCIA
slot
Gigabit
Ethernet
port
155Mbps
optical port
10/100
Ethernet
port
Diagnostic
port
Alarm
input port
Modem
port

PCMCIA slot

This slot is supported on the IP2000 module and control module. It holds PCMCIA
cards that can store configuration information and software for the Stinger unit.
You remove the PCMCIA cards by pushing the square, flat black buttons at the
bottom of each PCMCIA card to eject it. After a card is removed, make sure it remains
guarded against static discharge.
You install the PCMCIA cards by aligning the card edge with the slot guides, and
pushing the card in until the black ejector button pops up.
3-32
Holds PCMCIA cards for storage of
configuration settings and software
High bandwidth connection for
end-user traffic
High bandwidth connection for
end-user traffic and management
information
Low bandwidth connection to
management network
Serial connection for management
console
Connections to monitor the status
of up to seven external alarm
A special cable, required with the
IP2000 module, monitors the
enclosure door alarm through the
Alarm port. (See, "Door alarm
connection for stand-alone
operation" on page C-20.)
Dial-up connection to the
management interface
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
