Intended Use

IP2000 interfaces

A DB-9 female connector for alarm monitoring connections.
A duplex LC connector for optical connection.
IP2000 interfaces
The IP2000 is equipped with the following interfaces:
A DB-9 female connector for an RS-232 serial connection, with the following
default settings:
A DB-9 female connector for alarm monitoring connections (revision 2 control
modules).
An RJ-45 connector for a 10/100BaseT Ethernet connection.
An RJ-11 connector for the optional internal modem.
A PCMCIA interface, designed to accept PCMCIA flash-memory cards. Other
PCMCIA devices are not supported.
A duplex LC connector for optical connection.

Control module interfaces

The control module is equipped with the following interfaces:
A DB-9 female connector for an RS-232 serial connection, with the following
default settings:
A DB-9 female connector for alarm monitoring connections (revision 2 control
modules).
An RJ-45 connector for a 10/100BaseT Ethernet connection.
An RJ-11 connector for the optional internal modem.
A-2
Direct connection
8 data bits
No parity
1 stop bit
No flow control
9600bps
Direct connection
8 data bits
No parity
1 stop bit
No flow control
9600bps
Direct connection
8 data bits
No parity
1 stop bit
No flow control
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
