Protector orientation details

The cables from the LPMs connect to the protected (inside) side of the protection
blocks. Another group of cables connect the unprotected (outside) side of the
protection blocks to the copper facilities. The tips and rings of the outside plant cables
and the LPM cables terminate on the protection plugs of the protection blocks as
shown in Figure C-6.
Figure C-6.
For information about the type of protection elements that should be installed, see
"Protection block elements" on page D-5.

Connection block LPM cable associations

Each pair of protection blocks have similar cable connections to an LPM in the
Stinger unit. The connection of the LPM connectors P2801, P2802, and P2803 to the
protection blocks is described in Table C-3 and Table C-4.
LPM connections for the top protection block (blocks 1, 3, and 5) are detailed in
Table C-3. When a T1/IMA LIM is installed in one of the LIM slots, up to 24 4-wire
ports are supported and mapped as shown. The numbering for protectors on P1, P3,
and P5 corresponds to the protector numbering in Figure C-5 on page C-6.
Table C-3.
P1
(LPM 1)
1T
1R
2T
2R
3T
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Protection plug orientation example
Tip
(outside plant)
Ring
(outside plant)
Tip/Ring connections to protection blocks 1, 3, and 5
P3 P5 LPM
(LPM 2) (LPM 3) connector
49T 97T P2801
49R 97R P2801
50T 98T P2801
50R 98R P2801
51T 99T P2801
Cables and Connectors
Cabling for the 48-port LPM with splitters
Tip
(LPM)
Ring
(LPM)
Pin No. LPM 2-wire
ports
33 1T(ADSL)
1 1R(ADSL)
34 2T(ADSL)
2 2R(ADSL)
35 3T(ADSL)
LPM 4-wire
ports
1T(XMT)
1R(XMT)
1T(RCV)
1R(RCV)
2T(XMT)
