Introduction to the Stinger
Compact Remote ATM DSLAM

Stinger Compact Remote ATM DSLAM overview . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Stinger Compact Remote ATM DSLAM Hardware . . . . . . . . . . . . . . . . . . . . . . . 1-4
Host hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Stinger Compact Remote ATM DSLAM overview
The Stinger Compact Remote ATM DSLAM (CR ATM DSLAM) is a
temperature-hardened unit that can be installed outdoors, close to subscriber
locations. Power is provided over dedicated copper telecommunications facilities
from the central office. It can be configured with different hardware components to
function as a small stand-alone ATM digital subscriber line access multiplexer (ATM
DSLAM), or as a hosted optical network unit (ONU).

Stand-alone operation

The Compact Remote ATM DSLAM unit is configured for stand-alone operation with
the same procedures used to configure a Stinger FS or Stinger LS unit in a central
office. Configuration and management of the unit is handled through the local TAOS
management interface. The interface and all local configuration and management
capabilities are provided by installing the correct standard control module, or IP2000
control module in the unit.
Individual subscriber lines are physically terminated on the line interface modules
(LIMs) of Stinger Compact Remote ATM DSLAM unit. A Stinger CR ATM DSLAM
unit that is equipped for stand alone operation with an IP2000 control module,
routes subscriber traffic over the gigabit Ethernet interface of the IP2000 module
installed in the COP slot. A Stinger CR ATM DSLAM unit that is equipped for stand
alone operation with a standard control module in the COP slot, routes subscriber
traffic over the T1 interfaces of a TI-IMA module in one of the LIM slots.
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
