Initial Stand-alone Configuration
Providing a basic system IP configuration
the network, other than the single address that is specified. It is, in effect, a
one-address subnet.

Assigning the Ethernet IP addresses

A Stinger CR ATM DSLAM unit creates an IP interface for each Ethernet port of the
IP2000 or control module. Use the Dir command to list the IP interfaces, as follows:
admin> dir ip-interface
18
01/25/2004 16:36:32
29
01/25/2004 16:27:57
18
01/25/2004 23:53:47
Interface number
Gigabit Ethernet interface, which will only be seen if an IP2000 module is installed.
Note
The IP-Interface profile with the zero index (the default any-shelf
any-slot index) is used for a soft interface. The soft interface can be used to provide
a common address for access to redundant IP2000 or control modules in systems that
support redundant controlling modules.

The 10/100BaseT Ethernet interface

The 10/100Base T Ethernet interface can be configured to provide a separate
connection to a dedicated administrative network. This is common for Stinger units
in locations where there is access to a 10/100Base T administrative network.
In this example, the 10/100BaseT interface on the unit is assigned the IP address
1.1.1.1 with a 24-bit netmask:
admin> read ip-interface { { shelf-2 8 1 } 0 }
IP-INTERFACE/{ { shelf-1 first-control-module 1 } 0 } read
admin> set ip-address = 1.1.1.1/24
admin> write
IP-INTERFACE/{ { shelf-1 first-control-module 1 } 0 } written
After you assign IP addresses, you can verify that the Stinger unit is a valid IP host on
its configured network by pinging other network hosts, as shown in the following
example:
admin> ping 1.1.1.56
PING 1.1.1.56: 56 Data bytes
64 bytes from 1.1.1.56: icmp_seq=0 ttl=255 time=0 ms
64 bytes from 1.1.1.56: icmp_seq=3 ttl=255 time=0 ms
^C
--- 1.1.1.56: Ping statistics ---
2 packets transmitted, 2 packets received, 0% packet loss
round-trip min/avg/max = 0/0/0 ms

The IP2000 Gigabit Ethernet interface

In remote locations, where three is no access to a 10/100Base T Ethernet network,
connection to an administrative network can be configured for the Gigabit Ethernet
port.
In this example, the Gigabit Ethernet interface on the IP2000 is assigned the IP
address 1.1.1.2 with a 24-bit netmask:
4-12
{ { any-shelf any-slot 0 } 0 }
{ { shelf-1 first-control-module 1 } 0 }
{ { shelf-1 first-control-module 2 } 0 }
is the 10/100 Ethernet interface. Interface number
1
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
is the
2
