Table D-3.
Specification
Physical characteristics
Enclosure size
Unit weight
1. The overall measurements include clearance for cabinet hardware, locking mechanism, ventilation
shrouds, and cable cover.

Site specifications

Stinger units require a particular operating environment and minimum clearance for
proper operation.

Operating environment

Table D-4 describes the environmental requirements for selecting an installation site
for the Stinger CR hardware. The site requirements are based on Network Equipment
Building System (NEBS) GR-63-CORE and GR-1089-CORE.
Table D-4. Stinger CR site specifications
Parameter
Ambient operating
temperature
Relative humidity
Operating altitude
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Safety-Related Electrical, Physical, and Environmental Information
Stinger CR physical specifications (Continued)
Description
Basic unit includes one populated Stinger CR chassis
(cooling fan module, control and optics pack, power
supply, and three 48-port LIM/LPM pairs), in an outdoor
chassis with protector blocks and cabling.
1 Height (enclosure only): 30.1 inches (76.5cm)
Height (overall): 40.5 inches (102.9cm)
Depth (enclosure only):
hosted units—11.5 inches (29.2cm)
stand-alone units—12 inches (30.5cm)
Depth (overall): 12.6 inches (32cm)
Width (enclosure only): 16.2 inches (41.2cm)
Width (overall): 20.5 inches (52cm)
121 pounds (54.885kg) maximum (with fans, power
supply, protections blocks, and cables)
Requirement
Light gray enclosures (fully populated:
-40°C to 46°C (-40°F to 114.8°F)
Green enclosures with IP2000 modules and 2
LIM/LPM circuit packs (maximum):
-40°C to 46°C (-40°F to 114.8°F)
Brown or green enclosures (fully populated):
-40°C to 40°C (-40°F to 104°F)
10% to 95% (noncondensing)
To 13,123 feet (4000 m)
Site specifications
D-9
