Preparing to Install the Unit
Installation tools and equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Preventing static discharge damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Unpacking the Stinger Compact Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Verifying the hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Checking modules and chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Installation tools and equipment
To install and configure the Stinger CR ATM DSLAM hardware and software, you
need the following tools and equipment.
Physical installation:
Antistatic wrist strap (Internal Lucent number: R-4987C)
SC and LC fiber optic connector cleaner (Cletop, Optipop, or equivalent)
Utility knife, or appropriate tool for striping wire insulation
Screwdrivers
#1 cross-recess (phillips)
1/8-inch flathead
3/16-inch flathead
Safety screw driver for removal and installation of tribunal recessed head
screws (Part number 29-99-183-22, available from Southco Inc., or
equivalent)
Wrenches and sockets
3/8-inch wrench or socket
7/16 inch wrench or socket
1 inch open end wrench
7/16 standard hex key (can wrench or thin-wall socket for enclosure door
latches)
A 15/16 in. socket with a 2 in. extension (min.)
(Optional) 10 inch tongue & groove (channel lock) pliers
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
2
2-1
2-2
2-4
2-5
2-6
2-1
