Figure 2-4 Front View Of A Stinger Compact Remote Atm Dslam Chassis - Lucent Technologies Stinger Compact Remote Getting Started Manual

electrostatic discharge (ESD) grounding jack (banana jack), located at right side of the
chassis (Figure 2-4).
Figure 2-4.
Air exhaust
Power supply
Caution
!
colors, light gray, brown, and green. Because of the heat dissipation characteristics,
the maximum operating temperature for brown enclosures is 104°F (+40°C). Also,
green enclosures equipped with an IP2000 module must not contain more than two
sets of LIM/LPM modules in environments where ambient temperatures exceed
104°F (+40°C).
Caution
!
to ensure proper air flow through the unit.
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Front view of a Stinger Compact Remote ATM DSLAM chassis
COMPACT REMOTE
LPM 1 LIM
LIM slots
1
4
7
LPM slots 10
13
16
19
22
25
28
31
34
37
40
43
46
LPM 1 LIM
POWER INPUTS
+190V
-190V
Stinger Compact Remote ATM DSLAM enclosures are produced in three
Slots that are not occupied by modules must be masked with blank covers
COOLING UNIT STATUS
INTERNAL
BLINKING GREEN: INITIALIZING, GREEN: ACTIVE, RED: FAULT
1 LPM 2 LIM 2 LPM 3 LIM 3
1
1
4
4
7
7
10
10
13
13
16
16
19
19
22
22
25
25
28
28
31
31
34
34
37
37
40
40
43
43
46
46
1 LPM 2 LIM 2 LPM 3 LIM 3
V.CHECK
STATUS
-48V 0V
COMPACT REMOTE POWER SUPPLY
Preparing to Install the Unit
Checking modules and chassis
Cooling unit
EXTERNAL
COP
Control (COP) slot
(COP module
shown)
ESD grounding
point
FAULT
TA
MISC
FAC
COP
2-7
