Intended Use
User line interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
COP interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
IP2000 interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Control module interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
The Stinger CR ATM DSLAM unit is remote Stinger unit that operates in hosted
mode to extend the capability of a host Stinger DSL ATM switch. It provides DSL
connections for individual users that are too far from the Stinger host to be directly
connected to it.
Users connect to the Stinger CR ATM DSLAM over DSL lines supported by line
interface modules (LIMs) that are installed in the Stinger CR ATM DSLAM unit.
Every Stinger CR ATM DSLAM unit contains a special COP module that controls the
operation of the unit and provides an OC3 link to the host Stinger unit. The physical
interfaces on the unit provide DSL or ATM network connections to digital lines, and a
serial connection for configuration and administration, an OC3 optical port, and an
interface for monitoring the alarm status of other devices.

User line interfaces

The 48-port low-power ADSL LIM designed for use with the Stinger Compact
Remote ATM DSLAM allow users to connect to the Stinger unit over DSL lines
supporting the following DSL protocols:
G.992.3 Annex A (G.dmt.bis)
G.992.4 Annex A (G.lite.bis)
G.992.5 Annex A (G.adsl2plus)
User connection to each LIM is provided through an associated line protection
module (LPM).

COP interfaces

The COP is equipped with the following interfaces:
A DB-9 female connector for an RS-232 serial connection, with the following
default settings:
– 9600bps
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
