Physical connections to the components
Figure 3-25. 155Mbps optical connection to the COP

10/100 Ethernet port

This port is supported on the IP2000 module and control module. This port can
connect the Stinger CR ATM DSLAM unit through an Ethernet network or, with an
Ethernet turnover cable, directly to an administrative workstation. The IP address of
the Stinger CR ATM DSLAM unit must be configured and the unit must be connected
to an Ethernet network, or workstation before this port can be used.
Figure 3-26 shows an Ethernet network connection from the Stinger unit to a
management workstation.
Figure 3-26. Ethernet connection
