Cables and Connectors

Modem jumper cable

Table C-1.
DB-9 pin number
6
7
8
1
9
1. Pin 9 is not active. (Ring Indication signal not supplied.)
Modem jumper cable
The modem jumper cable is only used on units that are equipped with the
STGR-CM-B control module, containing an internal modem. This jumper cable
connects the analog service for this modem.
Analog service for the modem is provided on Molex connector P9, located below the
protection blocks. One end of the jumper cable attaches to this connector with a
compatible Molex connector. The other end is equipped with a standard RJ-11
connector that connects to the control module MODEM port. This cable is shown in
Figure C-1.
Figure C-1.
C-2
Control port and cable pinouts (Continued)
RS-232 signal
name
DSR
RTS
CTS
RI
Modem jumper cable and connectors
Molex Connector
Connector P9
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Function I/O
Data Set Ready O
Request to Send I
Clear to Send O
Ring Indicator O
406.4mm
(16 In.)
RJ-11 connector
