Introduction to the Stinger Compact Remote ATM DSLAM
Host hardware
Figure 1-5.
OLIM
When an OLIM is installed in the host Stinger unit, you can create profiles that are
associated with the Compact Remote ATM DSLAM units that are connected to it.
These profiles in the management interface of the host unit, allow the Stinger CR
ATM DSLAM units and the Stinger host to be managed through the same interface.
See Chapter 5 for detailed information about these profiles and the configuration of a
hosted Stinger CR ATM DSLAM.
The type of optical network created by hosted Stinger Compact Remote ATM DSLAM
units is illustrated in Figure 1-6.
1-10
OLIMs installed in a Stinger FS+ host
STINGER FS
+
FAULT
FAC 1
FAC 2
FAC 3
FAC 4
FAC 5
FAC 6
PORT 1
PORT 6
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
FAULT
FAC 1
FAC 2
OLIM
FAC 3
FAC 4
FAC 5
FAC 6
PORT 1
PORT 6
