Cables and Connectors
Cabling for the 48-port LPM with splitters
Table C-4.
P2
(LPM 1)
29T
29R
30T
30R
31T
31R
32T
32R
33T
33R
34T
34R
35T
35R
36T
36R
37T
37R
38T
38R
39T
39R
40T
40R
41T
41R
C-14
Tip/Ring connections to protection blocks 2, 4, and 6 (Continued)
P4 P6 LPM
(LPM 2) (LPM 3) connector
77T 125T P2803
77R 125R P2803
78T 126T P2803
78R 126R P2803
79T 127T P2803
79R 127R P2803
80T 128T P2803
80R 128R P2803
81T 129T P2802
81R 129R P2802
82T 130T P2802
82R 130R P2802
83T 131T P2802
83R 131R P2802
84T 132T P2802
84R 132R P2802
85T 133T P2802
85R 133R P2802
86T 134T P2802
86R 134R P2802
87T 135T P2802
87R 135R P2802
88T 136T P2802
88R 136R P2802
89T 137T P2802
89R 137R P2802
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Pin No. LPM
connection
61 29T(POTS)
29 29R(POTS)
62 30T(POTS)
30 30R(POTS)
63 31T(POTS)
31 31R(POTS)
64 32T(POTS)
32 32R(POTS)
49 33T(POTS)
17 33R(POTS)
50 34T(POTS)
18 34R(POTS)
51 35T(POTS)
19 35R(POTS)
52 36T(POTS)
20 36R(POTS)
53 37T(POTS)
21 37R(POTS)
54 38T(POTS)
22 38R(POTS)
55 39T(POTS)
23 39R(POTS)
56 40T(POTS)
24 40R(POTS)
57 41T(POTS)
25 41R(POTS)
