Specific components that are installed in the Stinger Compact Remote ATM DSLAM
card-cage to support these functional requirements depend upon the operational
mode for which the unit is being configured. Different components are installed to
support stand-alone or hosted operation. The Table 1-1 identifies the components
that can be installed in the Stinger CR ATM DSLAM card-cage, the functions that
they provide, and the type of operation that they support.
Table 1-1. Functional listing of card-cage components
Component
Standard
control module
IP2000 control
module
COP
T1-IMA LIM
ADSL
LIM/RLIM
ADSL2+ LIM
SHDSL LIM
LPM with
splitters
Cooling unit
±190Vdc Power
supply
-48Vdc Power
supply
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Introduction to the Stinger Compact Remote ATM DSLAM
Function(s) provided
Operational control of the unit, including local
management interface for configuration and
management
Operational control of the unit, including local
management interface for configuration and
management
Upstream connection from a gigabit Ethernet
interface
Operational control of the unit (no local
management interface)
Upstream connection from a 155Mbps optical
interface
Upstream connections from T1 interfaces
DSL connections to individual end-users
Note A LIM in a hosted unit is identified as an
RLIM in the TAOS interface of the host.
DSL connections to individual end-users
DSL connections to individual end-users
Physical connections for analog facilities from
the central office, and facilities providing
analog service with DSL to end-users.
Physical connections for T1 interfaces from an
adjacent T1-IMA LIM.
Operational support (cooling: self-contained
internal fan and power to an external fan)
Operational support (power conversion)
Operational support for native -48Vdc
Stinger Compact Remote ATM DSLAM hardware
Operational
mode
Stand-alone
Stand-alone
Hosted
Stand-alone
Hosted or
stand-alone
Stand-alone
Stand-alone
Hosted or
stand-alone
Stand-alone
Hosted or
stand-alone
Hosted or
stand-alone
Hosted or
stand-alone
