Preparing to Install the Unit
Unpacking the Stinger Compact Remote
Use the following two simple tests to verify that the wrist strap is functioning
properly:
Measure the resistance between the wrist strap and its grounding plug. Overall
resistance between these two points must be approximately 1 megohm. If it is
not, replace the strap.
Physically examine the strap for visible damage. If you see any damage, replace
the strap.
Remove plastics from your work area
Work areas must be kept clear of common plastics, such as the following items:
Polystyrene packing containers
Clear plastic bags
Plastic drinking cups
Food wrappers
Clear cellophane tape
These types of common plastic materials can carry a static charge that is not easily
discharged to ground and must not make direct contact with modules or any other
solid state components.
Store components properly
Protect modules immediately after removal from a chassis by placing them in their
original factory packing materials. Storage in approved antistatic packaging is
acceptable when factory packaging is unavailable.
Caution
!
or on ungrounded carts without insulating surfaces.
Unpacking the Stinger Compact Remote
The unit is delivered with the Stinger CR ATM DSLAM chassis installed in its
integrated outdoor enclosure. It may be shipped with all the ordered modules
installed, or with filler-blanks in the slots of the chassis card-cage. The unit is
delivered in a protective shipping carton attached to a wooden pallet with screws and
L-brackets.
Before you remove the Stinger CR ATM DSLAM unit from the shipping carton and
delivery pallet, check for damage. If you see any damage, follow the instructions
described in your product warranty.
Due to the large size and weight of a fully configured unit, Lucent Technologies
recommends moving the unit to the installation site before unpacking it from the
shipping carton.
Warning
!
cables weighs up to 121 pounds (54.885kg). This weight does not include protection
elements, LIMs, LPMs, or the COP. See"Weight and lifting requirements" on
page D-10 for detailed weight information.
To unpack the unit:
2-4
Never place unprotected modules directly on ungrounded metal shelving
A bare Stinger CR unit in its enclosure with its power supply, fans, and
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
