Safety-Related Electrical, Physical, and Environmental Information

Weight and lifting requirements

Table D-4. Stinger CR site specifications (Continued)
Parameter
Ambient storage
temperature and humidity
Storage altitude
Caution
!
of the enclosure, power should be applied to the Stinger CR as soon as possible after
installation.
Weight and lifting requirements
A fully loaded Stinger Compact Remote enclosure weighs approximately 160 pounds
(72.575kg). For ease of installation the unit should be installed without its modular
components in place. The following table will help you determine the weight of the
unit you are installing.
Table D-5.
Item
Bare system (includes card cage, solar
shields, and protection blocks)
Cooling unit and enclosure fan
Cables (with 20 foot external drops)
LIMs
LPMs
COP
Protection elements
1. Add an additional 5 pounds (2.268kg) for enclosure JWI 2700.
D-10
Requirement
-40°C to 85°C (-40°C to 140°F), 95% relative
humidity
-1,000 feet to +30,000 feet (-305m to 9150m)
To avoid damage from condensation and regulate the internal temperature
Stinger CR weight details
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Weight
1
74 pounds (33.566kg)
18 pounds (8.165kg)
29 pounds (13.154kg)
3.6 pounds (1.633kg) per LIM
3.3 pounds (1.497kg) per LPM
2.1 pounds (0.953kg)
10 pounds (maximum, fully equipped)
