Mounting the enclosure on a wiring cabinet
An existing wiring cabinet must be carefully prepared for mounting a Stinger CR.
Follow all local safety practices and guidelines in performing this work to avoid injury
and the interruption of existing service.
To install a Stinger Compact Remote enclosure on a pole, you need the following
items:
The Stinger enclosure and appropriate mounting kit
A hammer
An antistatic wrist strap (Lucent number: R-4987C or equivalent) for handling
components
A center punch
An electric drill
A 5/16 inch (7.5mm) drill bit
A 3/4 inch (19mm) metal hole saw
A knock-out punch (Greenlee)
A 10 inch (25cm) tongue and groove (channel lock) pliers
Safety screw driver for removal and installation of trilobular recessed head screws
(Part number 29-99-183-22, available from Southco Inc., or equivalent)
Three 1 inch liquid tight strain relief fitting (Bell SAP 233536 NM)
Three 3/4 inch liquid tight strain relief fitting (Bell SAP 595613 NM)
Prepare the cabinet and install the mounting bracket
Installation on an outdoor cabinet requires a total of four mounting holes and six
pass-through holes for cables from the Stinger CR unit. The mounting holes are 5/16
inch (7.5mm) in diameter. Three of the cable holes are 3/4 inch in diameter, and
three holes are 1 inch in diameter. These holes are marked with a template that is
supplied with the mounting kit.
If you are side-mounting the enclosure, you must remove the integrated
side-mounting bracket from the enclosure before beginning (see Figure 3-2 on
page 3-5). If you are rear mounting the enclosure, you must install the enclosure
hanger on the enclosure before beginning (see Figure 3-8 on page 3-10).
You may use the following general procedure to prepare the cabinet and install the
mounting bracket.
1
Pre-position the mounting template that is shipped with the mounting kit to
verify that all holes can be drilled without damaging existing cables or hardware
behind the mounting surface.
2
Mark the location of each mounting hole and cable pass-through hole and create
an indentation in the center of each location with a center punch.
Note
To protect them from damage during drilling, verify that no cables or wires are
routed near the locations where holes will be drilled.
3
Use a 5/16 inch (7.5mm) drill bit to drill the four mounting holes for the CR
mounting bracket.
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Enclosure and Component Installation
Mounting the enclosure on a wiring cabinet
3-13
