1 Beginning with the bottom connector, carefully insert the head of the cable into
the connector on the LPM, as shown in Figure 3-30.
2 Press the connector firmly into place until it is fully seated.
3 Using a number 1 cross-recess (Phillips) screwdriver tighten the lock screws at
the top and bottom of the connector.
4 Move up to the next connector and repeat step 1 through step 3 until the top
connector on the LPM has been installed.
Note See "Cabling for the 48-port LPM with splitters" on page C-3 for pinout
information and wiring details.

Routing the LPM connector cables

Prior to closing the enclosure door, the cables from each of the LPM connectors must
be routed to the side of the connectors.
Caution
door from closing properly, and may be damaged when attempting to close the door.
The cables from each LPM connector must be routed to the right of any lower
connectors, as shown in Figure 3-31, and routed in front of the adjacent LIM toward
the bottom of the enclosure. Below the LIM/LPM slots, the cables can be bundled
together and maintained in place with four cinch-wrap cable ties, as shown in
Figure 3-31.
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Any cable that remains over an LPM connector will prevent the enclosure
Enclosure and Component Installation
Physical connections to the components
3-39
