network connection from the Stinger CR ATM DSLAM unit to the management
workstation.
Note Although an IP2000 module is depicted, the same connection is made to a
control module in the same way. For connector details, see "Control module
interfaces" on page 2-8, and "IP2000 interfaces" on page 2-10.
Figure 4-2.
To connect a management workstation to the Stinger CR ATM DSLAM unit using an
indirect Ethernet connection:
1 Connect one end of the Ethernet cable to the Ethernet RJ-48 port on the IP2000 or control
module.
2 Connect the other end of the Ethernet cable to the local LAN.
3 Ensure that the management workstation has connectivity to the LAN on which the unit
resides.
4 Ensure the Ethernet transceivers are connected properly to the network.

Gigabit Ethernet connection to a workstation console

After the IP address for the Gigabit Ethernet port of a Stinger unit is configured, and
the unit is connected to a Gigabit Ethernet network, an administrative Telnet
connection can be established through the network. Figure 4-2 shows an Ethernet
network connection from the Stinger CR ATM DSLAM unit to the management
workstation.
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
10/100 Ethernet connection
COOLIN G UNIT COOLIN G UNIT
ST STATUS TUS
EXTER NAL EXTER NAL
INTERN AL INTERN AL
RED - FAUL ULT
RED - F
GREEN - A GREEN - ACTIVE CTIVE
- INITIALIZ ING - INITIALIZ ING
BLINKING GREEN BLINKING GREEN
COMP ACT REMO CT REMO TE TE
COMP
COP
LIM 3
3
2 LPM
LIM
LPM 2
1
1 LIM
LPM
LINK
10
ACT
100
Gig. E
ACT
LINK
COP
LIM 3
3
2 LPM
LIM
LPM 2
1
1 LIM
LPM
WER INPU TS TS V.CHE CK .CHE CK
POWE R INPU
PO
-48V -48V 0V 0V
STATU S TUS
ST
+190V +190V
WER SUP PLY PL
-190V -190V TE POW ER SUP
CT REM OTE O PO
COM PAC T REM
COM P
Initial Stand-alone Configuration
Ethernet
port
LIN K
10
ACT
100
Gig . E
ACT
LINK
Router
Administrative connections
Workstation
Ethernet port
4-3
