Hosted System Management
Monitoring the status of remote shelves
2 Z0WISAAASCR
Without any options, the command displays all configured remote shelves:
HOST> remoteshelf
Shelf Name
2 Z0WISAAASCR

Raising and clearing alarm events in a hosted system

Alarms triggered by events on remote shelves operate within the existing profile-
based alarm infrastructure, which is described in the Stinger Administration Guide. If
you configure an alarm to be active by setting its value to yes, an action is triggered
and volatile profiles are updated. An emergency level log message is generated
whenever the alarm is raised or cleared.

Configuring alarms for remote shelves

The following parameter, shown with its default setting, determines the scope of an
alarm event in a hosted system:
[in ALARM/""]
physical-address = { any-shelf any-slot 0 }
The default setting represents all remote shelves in the hosted system. To specify an
alarm event that will be triggered only when it occurs on the host itself, specify shelf
1. For example:
HOST> set physical-address shelf = shelf-1
To configure an alarm for a specific remote shelf, specify the ID of that shelf. For
example, to configure an alarm for shelf 2:
HOST> set physical-address shelf = shelf-2
An alarm profile specific to a remote shelf is deleted if the remote-shelf-config
profile for that shelf is deleted, and the corresponding alarms are cleared.

Remote shelf alarm events

Following are events related to Compact Remote shelves:
Table 6-1. Compact Remote alarm events
Alarm event definition
remote-shelf-state-
change
line-state-change
slot-state-change
fan-failure
6-8
Enabled OPER_Down {{ 1 5 2 } 0 }
AdminState OperState host-port
Enabled OPER_Down {{ 0 0 0} 0}
Event on remote shelf that triggers alarm
The remote shelf changes state. The new status is
shown in the remote-shelf-oper-state setting of the
remote-shelf-stat profile.
A change has been detected in the state of a DSL line on
the remote shelf.
A change has been detected in the state of a card in the
designated slot of the remote shelf.
A sensor on the remote shelf indicates failure of the
internal fan unit. The failed status is shown in the
internal-fan-unit-failed setting of the
remote-shelf-stat profile.
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
0
up-count
0
