Page 2 Information Product Support Number Lucent Technologies provides a referral telephone number for support. Use this number to report errors or to ask questions about the information in this information product. This is a non-technical number. The referral telephone number is: 1-888-727-3615 –...
Page 3 OptiStar™ EdgeSwitch Release 1.5 User Operations Guide 365-575-925R1.5 Issue 1, April 2002 Lucent Technologies welcomes your comments on this information product. Your opinion is of great value and helps us to improve. Was the information product: applicable In the language of your choice? In the desired media (paper, CD-ROM, etc.)?
Page 4 THIS PAGE IS INTENTIONALLY LEFT BLANK...
Page 5: Table Of Contents
2.2.2.2 Optical Power Budgets and Link Loss ................ 2-6 2.2.3 SAN Considerations ......................2-7 2.2.4 LAN Considerations......................2-8 2.2.5 Configuration Planning ...................... 2-8 2.3 Ordering Information ......................2-8 2.3.1 OptiStar EdgeSwitch Comcodes ..................2-9 2.3.2 GBIC Transceiver Modules ....................2-9 2.4 Cabling Requirements ......................2-10 Lucent Technologies 365-575-925R1.5...
Page 6 4.4 User Management ........................ 4-14 4.5 Assigning IP Addresses ...................... 4-16 4.5.1 How to Set up IP Addresses on the OptiStar EdgeSwitch without Bridging ....4-16 4.5.2 How to Set Up IP Addresses on the OptiStar EdgeSwitch with Bridging ......4-17 4.6 Setting up a Static Route and Checking IP Connectivity..........
Page 7 4.10.1.5 Enforcement of Previously Activated Zone Sets—Zone Merge......4-45 4.10.1.6 Joining Zoned Fabrics..................... 4-47 4.10.2 How to Configure & Activate WWN Zoning on the OptiStar EdgeSwitch...... 4-48 4.11 Exporting/Importing the OptiStar EdgeSwitch Configuration........4-50 4.11.1 Export Configuration File ....................4-50 4.11.2 Import Configuration File ....................
Page 8 5.3.2.4 Set System Temperature Threshold................. 5-23 5.3.2.5 Set Time Server IP Address ..................5-23 5.3.2.6 Set System with Default Values ................5-23 5.3.2.7 Reset OptiStar EdgeSwitch ..................5-24 5.3.3 Port Parameters ......................5-24 5.3.3.1 Set 10/100BaseT Port Parameters................5-24 5.3.3.1.1 Set Auto Negotiation Mode for 10/100BaseT Port............5-24 5.3.3.2 Set Console Port Parameters ...................
Page 9 5.4.1.1 Get Authentication Parameter................... 5-49 5.4.1.2 Modify Administrator User Name and Password ............5-50 5.4.2 Set Module Admin Status ....................5-50 5.4.3 SNMP Configuration......................5-50 5.4.3.1 Set SNMP Trap Interval .................... 5-50 Lucent Technologies 365-575-925R1.5 CONTENTS Issue 1, April 2002...
Page 10 6.1.3.3.4 Configure WWN Zone Sets ....................6-10 6.1.3.3.5 Configure WWN Zones ....................6-15 6.1.4 Set Port Parameters ......................6-19 6.1.4.1 General Description ....................6-19 6.1.4.2 Show Current Port Settings ..................6-21 6.1.4.3 Set Port Type ......................6-22 Lucent Technologies CONTENTS 365-575-925R1.5 Issue 1, April 2002...
Page 11 6.1.8 Set Communication Parameters ..................6-49 6.1.8.1 General Description ....................6-50 6.1.8.2 Show Current Communication Settings ..............6-50 6.1.8.3 Set Console Mode ....................6-50 6.1.8.3.1 General Description ......................6-51 6.1.8.3.2 Show Current Console Settings ..................6-51 Lucent Technologies 365-575-925R1.5 CONTENTS Issue 1, April 2002 v i i...
Page 12 6.3.11.2 Show Link Connection Statistics................6-72 6.3.11.3 Show Link Data Statistics ..................6-72 6.3.11.4 Show Link Protocol Statistics.................. 6-72 6.3.11.5 Clear Link Statistics ....................6-73 6.3.12 Show SNS Table ......................6-73 Lucent Technologies CONTENTS 365-575-925R1.5 v i i i Issue 1, April 2002...
Page 13 9.1 Lucent Technologies Customer Support ................9-2 9.2 Lucent OnLine Customer Support ..................9-2 9.3 Product Updates ........................9-2 APPENDICES..........................AP-1 Appendix A: QuickStart Checklist & Planning Worksheet for a Typical OptiStar EdgeSwitch Configuration..........................AP-2 Appendix B: OptiStar EdgeSwitch CLI Menu Structure ............AP-8 Lucent Technologies 365-575-925R1.5...
Page 14 Appendix E: Preventing Electrostatic Discharge..............AP-27 Appendix F: OptiStar™ EdgeSwitch Warranty..............AP-28 Appendix G: OptiStar™ Software License & Disclaimer of Warranties ......AP-30 Appendix H: Environmental and Regulatory Information........... AP-33 Appendix I: Cable Ordering....................AP-36 Index.............................IN-1 Lucent Technologies CONTENTS 365-575-925R1.5 Issue 1, April 2002...
Page 15: Table Of Figures
Figure 2-1: Network Diagram..........................2-2 Figure 2-2: Potential Points of Failure in Simple SAN/WAN Application ............2-4 Figure 2-3: High Availability Example #1- 1 OptiStar EdgeSwitch with Dual WAN and FCIP Network Modules2-5 Figure 2-4: High Availability Example #2 - Dual OptiStar EdgeSwitches............2-5 Figure 3-1: Installing the Bracket using a Phillips head screwdriver..............3-4...
Page 16: About This Information Product
This information product is intended for use by network engineers, installers, system administrators, and technical support personnel who require documentation on the OptiStar EdgeSwitch. How to use this This user guide consists of reference chapters that provide a product overview,...
Page 17 • Rack-Mounting Instructions • Safety Guidelines • Installation of Add-In Modules • Connecting the Cables • Powering on the OptiStar Chapter 4, OptiStar EdgeSwitch EdgeSwitch Configuration • Accessing the Firmware • Setting Up Security • User Management • Assigning IP Addresses •...
Page 18 OptiStar EdgeSwitch firmware release 1.5. Related training The following OptiStar EdgeSwitch course will be provided by the Lucent Learning National Product Training Center: • Title: OptiStar EdgeSwitch Installation and Operations Course...
Page 19 U.S.). How to order The OptiStar EdgeSwitch documents can be ordered as individual paper copies or as a set on CD-ROM from the Customer Information Center (CIC). To order documents, specify the document or CD-ROM you need by select code.
Page 20 THIS PAGE IS INTENTIONALLY LEFT BLANK Lucent Technologies x v i 365-575-925R1.5 Issue 1, April 2002...
Page 21: Important Safety Instructions
To reduce the risk of electrical shock, do not disassemble this product. Service should be performed by trained personnel only. Opening or removing covers and/or circuit boards may expose you to dangerous voltages or other risks. Incorrect re-assembly can cause electric shock when the unit is subsequently used. Lucent Technologies 365-575-925R1.5 x v i i...
Page 22 If the product has been dropped or the cabinet has been damaged. If the product exhibits a distinct change in performance. HESE NSTRUCTIONS Lucent Technologies x v i i i 365-575-925R1.5 Issue 1, April 2002...
Page 23: Laser Safety Guidelines
Optical fiber telecommunication systems are generally classified as Class I/1, because, under normal operating conditions, all energized laser transmitting circuit packs are terminated on optical fibers which enclose the laser energy with the fiber sheath forming a protective housing. Also, a Lucent Technologies 365-575-925R1.5 x i x...
Page 24 Lucent Technologies 365-575-925R1.5 Issue 1, April 2002...
Page 25: Figure 1-4: Gigabit Ethernet Network Module
Fibre Channel Network Module 0.320 MM(62.5/125) with Multimode Fiber GBIC Lucent Technologies OPTISTAR EDGESWITCH complies with FDA/CDRH 21 CFR 1040.10 and 1040.11 as a Class I laser product and as an IEC 60825-1 2002 Class 1 laser product. Lucent Technologies 365-575-925R1.5...
Page 26 THIS PAGE IS INTENTIONALLY LEFT BLANK Lucent Technologies x x i i 365-575-925R1.5 Issue 1, April 2002...
Page 27: Chapter 1 Product Overview
Product Overview CHAPTER 1 Product Overview Lucent Technologies 365-575-925R1.5 1 - 1 Issue 1, April 2002...
Page 28: Product Introduction
CHAPTER 2 for more information about OptiStar EdgeSwitch applications. Installation: The OptiStar EdgeSwitch, at a height of 3 units (the exact chassis height is 5.18 inches), fits into any standard 19-inch rack or on a tabletop. Interfaces: The OptiStar EdgeSwitch integrates LAN, WAN and SAN access in a single device.
Page 29: Product Diagram
10. Fan Module 11. Rack mount brackets fit standard 19-inch racks (not shown, attach at sides of unit) Note: The specific configuration of the OptiStar EdgeSwitch is dependent upon which selection of add-in modules were ordered. All modules come pre-installed.
Page 30: Figure 1-2: Oc-48C/Stm-16C Network Module
OPTISTAR EDGESWITCH NETWORK MODULES Figure 1-2: OC-48c/STM-16c Network Module Figure 1-3: OC-12c/STM-4c Network Module Figure 1-4: Gigabit Ethernet Network Module Figure 1-5: FCIP Network Module Lucent Technologies 1 - 4 365-575-925R1.5 Issue 1, April 2002...
Page 31: Product Features
• Up to 1K ARP entries per port provided in CAM • On Layer 2, Gigabit Ethernet (GbE) card only, the OptiStar EdgeSwitch supports up to 8K FD entries Power • Power module and redundant power module shipped with unit •...
Page 32: System Hardware
(COM port) of a PC or laptop for out-of-band SNMP Network Management. It can also be used to configure the OptiStar EdgeSwitch also via the Command Line Interface (CLI) using terminal emulation software .
Page 33: Power On Self-Test (Post)
1.4.1.4 Reset Button The OptiStar EdgeSwitch has a recessed reset button on the lower left hand side of the Host Controller Module. The reset button should be used only when the system does not respond to any other prompt and the OptiStar EdgeSwitch has not initiated a cold reset.
Page 34: Power Module
OptiStar EdgeSwitch switch fabric. Each OptiStar EdgeSwitch FCIP Network Module can communicate to up to 239 other OptiStar EdgeSwitch FCIP Network Modules. The number is limited by the available Fibre Channel domains and some addresses are reserved. The domain number is an 8-bit hexadecimal value, ranging from x01-xEF.
Page 35: Features
Product Overview 1.4.3.1 Features The FCIP Network Module enables the OptiStar EdgeSwitch to support the following features: • Fibre Channel tunneling over OC-12c/STM-4c, OC-48c/STM-16c and Gigabit Ethernet WAN links • Two 1 Gbps Fibre Channel switch ports per network module •...
Page 36: Led Indicators
FCIP Network Module is establishing Flashing Flashing connectivity to the OptiStar EdgeSwitch. 1.4.4 OC-48c/STM-16c Network Module The OC-48c/STM-16c Network Module provides one port of Packet over SONET/SDH (PoS) OC-48c/STM- 16c for network connectivity at 2.5 Gbps. (The OC-48c/STM-16c Network Module runs at slightly less than full line rate under certain operating conditions.) This single port module is hot swappable and is plugged into the...
Page 37: Features
LC type connector. Note that for both ports, scrambling is always on. Also, the PPP links must be operational for the port to establish communications. The PPP control link will not have keepalive on, but will respond to keepalive messages from the far end. Lucent Technologies 365-575-925R1.5 1 - 1 1...
Page 38: Features
1.4.5.1 Features The OC-12c/STM-4c Network Module enables the OptiStar EdgeSwitch to support the following features: • High speed (622 Mbps) network connectivity • Single mode network interconnection for extended distance (up to 15 km) communications • Built-in IP services •...
Page 39: Led Indicators
1.4.7 Fan Module The OptiStar EdgeSwitch uses a Fan Module with four single speed fans. The OptiStar EdgeSwitch management system will get a temperature alarm if there is a fan failure and the temperature inside the system goes over a fixed threshold.
Page 40: System Firmware
See Section 4.2.1 for details on how to use the CLI. Web-based Management. The OptiStar EdgeSwitch can also be managed via a standard web browser (Internet Explorer 5.0 or higher and Netscape Communicator 4.xx or higher). See Section 4.2.2 for details on how to use web-based management.
Page 41: Chapter 2 Planning And Ordering
Planning and Ordering CHAPTER 2 Planning and Ordering Lucent Technologies 365-575-925R1.5 2 - 1 Issue 1, April 2002...
Page 42: Application Overview
Shown below is a simple, generic architecture for an OptiStar EdgeSwitch FCIP application that interconnects two remote SANs over an IP MAN/WAN. Each OptiStar EdgeSwitch connects to the IP WAN via a WAN module port, which could be Gigabit Ethernet, OC-48c/STM-16c or OC-12c/STM-4c Packet over SONET/SDH.
Page 43: Engineering Considerations
LAN over the IP WAN links shared with the FCIP traffic. 2.2 Engineering Considerations Due to the role of the OptiStar EdgeSwitch as a bridge between SAN, LAN, and MAN/WAN networks, there are a variety of factors that network planners and engineers should consider when designing an OptiStar EdgeSwitch application.
Page 44: Figure 2-2: Potential Points Of Failure In Simple San/Wan Application
Figure 2-2: Potential Points of Failure in Simple SAN/WAN Application The OptiStar EdgeSwitch supports high application availability requirements by using routing protocols (e.g. FSPF and OSPF) within the SAN/WAN network to re-route traffic over a secondary path when the primary path is not available.
Page 45: Figure 2-4: High Availability Example #2 - Dual Optistar Edgeswitches
WAN module on the OptiStar EdgeSwitch (an OC-12c Network Module in this example) to the WAN, and then to an OptiStar EdgeSwitch with a similar configuration on the other side of the network. As long as the primary path is healthy, the routing protocol will choose this path (since it has previously been assigned as the best available path via the routing configuration parameters).
Page 46: Man/Wan Considerations
In some cases it may be necessary to adjust the optical power level on the WDM or SONET/SDH system that the OptiStar EdgeSwitch is connecting to, in order to ensure that the link is reliable. The optical power budget may be viewed as the amount of optical power available to overcome the attenuation within the optical link.
Page 47: San Considerations
If the SAN environment includes Fibre Channel arbitrated loop devices or hubs, it is also important to know whether the OptiStar EdgeSwitch will be connecting to a private or public loop device. This will alert you as to having to change the FCIP Network Module switch mode of operations in order to be able to support both public loop and private loop devices at the same time.
Page 48: Lan Considerations
IP network, as well as the associated subnets that may already be in use at the site. This applies both to any Gigabit Ethernet port IP assignments being used in the OptiStar EdgeSwitch to connect to the LAN side of the network, as well as to the IP address to be assigned to the OptiStar EdgeSwitch 10/100 Ethernet management port.
Page 49: Optistar Edgeswitch Comcodes
2.3.2 GBIC Transceiver Modules The Gigabit Interface Converter (GBIC) Transceiver Modules used by the FCIP and Gigabit Ethernet Network Modules may be ordered through Lucent Technologies or customers may wish to procure them from another source. Lucent Technologies 365-575-925R1.5...
Page 50: Cabling Requirements
The table below outlines the cabling requirements for each port type on the OptiStar EdgeSwitch. The connector type listed indicates only what is required to connect to the OptiStar EdgeSwitch port, and may or may not be the same connector type required for the other end of the cable. For cable ordering information, please refer to Appendix I.
Page 51: Chapter 3 Hardware Installation
Hardware Installation CHAPTER 3 Hardware Installation Lucent Technologies 365-575-925R1.5 3 - 1 Issue 1, April 2002...
Page 52: Unpacking The Optistar Edgeswitch Shipping Carton
Choose a location to install the OptiStar EdgeSwitch and take the shipping carton to that location. To prevent damage to the OptiStar EdgeSwitch, do not remove it from the shipping carton until a location has been chosen and you are ready to install it.
Page 53: Rack-Mounting Instructions
Keep in mind the power and cabling requirements that need to be met and the necessary environmental conditions that need to be maintained. In order to install the OptiStar EdgeSwitch, you will need to obtain the following items before you begin: •...
Page 54: Figure 3-1: Installing The Bracket Using A Phillips Head Screwdriver
OptiStar EdgeSwitch. • Maintain a clearance of at least 3 inches (7.62 cm) at the sides of the OptiStar EdgeSwitch to ensure adequate air intake and exhaust. Note that the cooling air flow travels through the OptiStar EdgeSwitch from right to left when facing the front of the switch.
Page 55: Safety Recommendations
OptiStar EdgeSwitch may need to be placed on a shelf in the rack. Once the OptiStar EdgeSwitch is secured into the rack, attach both power cords to the back of the switch, and connect the pronged end of each power cord into a separate power circuit.
Page 56: Installation Of Optistar Edgeswitch Modules
3.4 Installation of OptiStar EdgeSwitch Modules 3.4.1 Slot Numbering Review the diagram below indicating the OptiStar EdgeSwitch slots and the location of the 10/100 port and the Console port. Determine which modules will go into each slot. Tip: Install the Modules in the bottom slots first.
Page 57: Installing The Gbic Modules
Module line up with the guides on the chassis. The Module is seated when the front panel of the Module is flush with the front panel of the OptiStar EdgeSwitch. Ensure that the release levers on the front edges of the modules are in a closed position (pressed against the front panel).
Page 58: Connecting The Cables
DB-9 Copper GBIC. Connect the other end of the cable to the appropriate Fibre Channel or Gigabit Ethernet device. Figure 3-8: HSSDC Cable to HSSDC Copper GBIC Figure 3-9: Multimode Fiber Cable to Multimode Fiber GBIC Lucent Technologies 3 - 8 365-575-925R1.5 Issue 1, April 2002...
Page 59: Connecting Cables For The Oc-48C/Stm-16C Network Module
Module port to another OC-48c/STM-16c device. Attach a single mode fiber cable (with LC connector) to the desired OptiStar EdgeSwitch OC-48c/STM-16c Network Module port. Connect the other end of the cable to the other OC-48c/STM-16c device (with LC, SC, FC, ST or other connector type).
Page 60: Management Cables
3.5.4 Management Cables To provide 10/100BaseT Ethernet connectivity to the management port, attach a Category 5 Ethernet cable (with RJ-45 connector) to the 10/100BaseT Ethernet management port on the OptiStar EdgeSwitch Host Controller Module. Figure 3-12: Category 5 Ethernet Cable with RJ-45 Connector to 10/100BaseT (Management) Port To provide serial port connectivity to the console port, attach a null modem cable (with 9-pin DB-9 connector) to the console port on the OptiStar EdgeSwitch Host Controller Module.
Page 61: Figure 3-14: Example Of One Of Each Type Of Network Module With Cables Attached
Hardware Installation The following picture is an example of what the OptiStar EdgeSwitch might look like after a complete installation. This example includes: • One OC-48c/STM-16c Network Module in slot #1 • One OC-12c/STM-4c Network Module in slot #2 •...
Page 62 THIS PAGE IS LEFT INTENTIONALLY BLANK Lucent Technologies 3 - 1 2 365-575-925R1.5 Issue 1, April 2002...
Page 63: Chapter 4 Optistar Edgeswitch Configuration
OptiStar EdgeSwitch Configuration CHAPTER 4 OptiStar EdgeSwitch Configuration Lucent Technologies 365-575-925R1.5 4 - 1 Issue 1, April 2002...
Page 64: Powering On The Optistar Edgeswitch
Subnet Mask. (Note: The 10/100BaseT port IP address and Subnet Mask can also be entered via the OptiStar EdgeSwitch CLI by following the menu path: [3] Configuration → → → → [4] IP Parameters → → → → [1] Set 10/100BaseT port IP Address and Mask) 4.1.1 Auto BootUp Process...
Page 65: Manual Bootup Process
“Press any key to enter BootUp Menu” If any key is pressed during POST or before the 7-second countdown ends, the OptiStar EdgeSwitch BootUp Menu will be displayed. Pressing the key causes the boot firmware to load the runtime firmware from the FLASH and write it to SDRAM.
Page 66: Accessing The Optistar Edgeswitch Firmware
4.2 Accessing the OptiStar EdgeSwitch Firmware Once the hardware has been initialized and the firmware has been downloaded, the OptiStar EdgeSwitch is ready to be configured. After the initial configuration is completed, the OptiStar EdgeSwitch can be managed in three ways: CLI - Command Line Interface.
Page 67: Logging On To The Cli Through Serial Link
Attach one end of a null modem cable with a DB-9 connector to the serial port on the management workstation. Attach the other end of the cable to the Console Port on the OptiStar EdgeSwitch. A standard DTE to DTE null modem cable can be used for connecting the port to a PC or laptop.
Page 68: Optistar Edgeswitch Access Priority Scheme
4.2.1.2 OptiStar EdgeSwitch Access Priority Scheme Since there are several methods by which a user can access the OptiStar EdgeSwitch, the system follows a pre- defined priority scheme to control multiple access attempts by a single user. There is no concurrency control of different users logged into the same OptiStar EdgeSwitch.
Page 69: Cli Function Keys
OptiStar EdgeSwitch Configuration Example 2: The user with User ID “optistar” is logged on to the CLI via the serial port. The user with the User ID “red” successfully logs on to the CLI via telnet. The user with the User ID “blue” also successfully logs on to the CLI via telnet.
Page 70: Cli Main Menu
OptiStar EdgeSwitch and will be used in the next boot up. Note: If this is the first time you have logged on to the OptiStar EdgeSwitch and the user name and password have not been changed from the defaults, you should change them now.
Page 71 OptiStar EdgeSwitch IP address to bypass the proxy.) Enter the IP address of the OptiStar EdgeSwitch as the URL in the Address field of the browser screen. For example, if the IP address of the OptiStar EdgeSwitch is 192.168.10.10 then enter the URL as shown: http://192.168.10.10...
Page 72: Web-Based Management Main Menu
4.2.2.2 Web-based Management Main Menu The OptiStar EdgeSwitch Web Configuration home page is set up with 2 frames. The left-hand frame contains a menu showing the management categories/functions on the OptiStar EdgeSwitch. The menu generally corresponds to the categories shown on the main screen of the CLI (see Section 4.2.1).
Page 73: Snmp Overview
Note: If this is the first time you have logged on to the OptiStar EdgeSwitch and the user name and password have not been changed from the defaults, you should change them now. For help, go directly to Section 4.3,...
Page 74: Setting Up Security
If you have not filled out the worksheet, you may wish to do so now, since it is an effective tool for summarizing and maintaining the information you will need to configure the OptiStar EdgeSwitch. Step 1 To set the Admin User Password, from the main menu follow the path: [4] Administration →...
Page 75: Setting Up Snmp Management
From the main menu, follow the path: [4] Administration Æ Æ Æ Æ [3] SNMP Configuration Æ Æ Æ Æ [2] Add NMS Entry Step 2 Enable the management station to access the OptiStar EdgeSwitch by entering the station’s IP address. Step 3...
Page 76: User Management
4.4 User Management The next step in setting up the OptiStar EdgeSwitch is to assign authorized users to the system. A maximum of 8 users (not including the super user) may be assigned to the system at any given time. Each user will be granted a set of “permissions”...
Page 77 OptiStar EdgeSwitch Configuration Step 2 For the first new user, enter the required information by following the system prompts: Enter Login UserName: Enter a login name that is a minimum of 6 and a maximum of 8 alpha-numeric characters in length Enter User’s Password: Enter a temporary login password for the user that is a minimum of 6...
Page 78: Assigning Ip Addresses
, you are ready to begin detailed configuration of the switch. The next step is to enter the IP addresses and corresponding subnet masks for all of the switching ports on the OptiStar EdgeSwitch. To set up the IP...
Page 79: How To Set Up Ip Addresses On The Optistar Edgeswitch With Bridging
Slot Numbering in Section 3.4.1 for help in determining correct module and port numbers. Empty slots on the OptiStar EdgeSwitch do not need to be configured. Step 3 To verify that the you have entered the IP addresses correctly, you may view the Switching Ports IP Address Table.
Page 80 Example: On OptiStar EdgeSwitch A, slots 2 & 3 contain Gigabit Ethernet Network modules. Let us assume Module 2/Port 1, Module 2/Port 2 and Module 3/Port 1 are going to do the bridging. Therefore these three ports should all be assigned to the same port group.
Page 81 Step 6 Now you are ready to assign IP addresses and the subnet mask. To configure the IP address and subnet mask for each interface (switching port) on the OptiStar EdgeSwitch, start at the main menu, then follow the path: [3] Configuration Æ...
Page 82: Setting Up A Static Route And Checking Ip Connectivity
Next, it is recommended that you verify IP connectivity between the ports that you have set up to be on the same IP subnetwork. To use the OptiStar EdgeSwitch Ping Utility to verify IP connectivity, from the main menu of the CLI, follow the path: [5] Utilities →...
Page 83: Setting Up Routing On The Optistar Edgeswitch
Note: This tutorial is not intended to provide detailed instruction on routing protocols or internetworking. Rather, its purpose is to help the user successfully navigate through the screens of the OptiStar EdgeSwitch to configure the switch as desired. For additional help on routing, protocols or network schematics, see your Network Administrator.
Page 84: Example Ip Network Configuration Between 2 Optistar Edgeswitches
192.168.3.100 Port Group #1 Subnet 192.168.3.0 Single-mode fiber connection 192.168.3.200 Port Group #1 € 192.168.8.100 € € OC-48 GigE OptiStar Port Group #4 EdgeSwitch B 192.168.7.100 Port Group #3 Lucent Technologies 4 - 2 2 365-575-925R1.5 Issue 1, April 2002...
Page 85: Rip Routing
IP connectivity between the ports that you have set up to be on the same IP subnet. To use the OptiStar EdgeSwitch Ping Utility to verify IP connectivity, from the main menu of the CLI, follow the path: [5] Utilities →...
Page 86 Note: You must enable the RIP Interface for each port that is designated to use RIP. Step 4 To verify that you have the desired Interface Status for each port on the OptiStar EdgeSwitch, from the main menu follow the path: [1] Operational Information & Status → → → → [7] Routing Information →...
Page 87: Ospf Routing
Next, returning to the General Group menu, select: [2] Router ID At the prompt, enter the IP address of the port on the OptiStar EdgeSwitch that will be the designated OSPF Router ID. Press the <Enter> key. Next, from the General Group menu, select: [3] AS Border Router If this OptiStar EdgeSwitch will be an AS Border Router, select (Yes), otherwise select (No).
Page 88 Return to the Set OSPF Parameters menu (from the main menu: [3] Configuration → → → → [6] Routing Step 7 Configuration → → → → [6] Set OSPF Parameters) then select: [3] Interface Group Æ Æ Æ Æ [1] Add Interface Entry Lucent Technologies 4 - 2 6 365-575-925R1.5 Issue 1, April 2002...
Page 89 OptiStar EdgeSwitch Configuration Step 8 Now you are ready to enable OSPF for the selected ports. Select a Slot (1-4) and a Port (1 or 2) to add as an OSPF Interface. Set the Interface Entry variables, referring to the following example table for help.
Page 90: Bgp4 Routing With Ospf For A Single Area
[2] Get OSPF Interface Status → → → → Enter Module (1-4) → → → → Enter Port (1-2) Step 10 In order for the new configuration to take effect, you must restart the OptiStar EdgeSwitch. From the main menu follow the path: [3] Configuration →...
Page 91 OptiStar EdgeSwitch Configuration As shown in the previous diagram, BGP4 routing is configured for the route connecting OptiStar EdgeSwitch A and B via the OC-48c ports on both switches. OSPF routing is configured for all other switching ports (in this case Gigabit Ethernet) that have connections to other devices on the network.
Page 92 BGP4. From the main menu follow the path: [3] Configuration → → → → [6] Routing Configuration → → → → [7] Set BGP4 Parameters → → → → [1] Set BGP4 General Parameters OptiStar EdgeSwitch A OptiStar EdgeSwitch B BGP Admin Status...
Page 93 [2] Get BGP Peer Table, then enter the BGP Peer #. Step 9 In order for the new configuration to take effect, you must restart the OptiStar EdgeSwitch. From the main menu follow the path: [3] Configuration → → → → [2] System Information → → → → [7] Reset OptiStar EdgeSwitch Lucent Technologies 365-575-925R1.5...
Page 94: Bgp4 Routing With Ospf For Multiple Areas
BGP4 Interface € € € OC-48 GigE OptiStar EdgeSwitch B 192.168.8.100 OSPF Interface Area ID: 20.20.20.20 192.168.7.100 OSPF Interface Multi-mode fiber connection Area ID: 10.10.10.10 Server Switch Server Area 20.20.20.20 Lucent Technologies 4 - 3 2 365-575-925R1.5 Issue 1, April 2002...
Page 95 OptiStar EdgeSwitch Configuration Step 4 As shown in the previous diagram, BGP4 routing is configured for the route connecting OptiStar EdgeSwitch A and B via the OC-48c ports on both switches. OSPF routing is configured for all other switching ports (in this case Gigabit Ethernet) that have connections to other devices on the network.
Page 96 BGP4. From the main menu follow the path: [3] Configuration → → → → [6] Routing Configuration → → → → [7] Set BGP4 Parameters → → → → [1] Set BGP4 General Parameters OptiStar EdgeSwitch A OptiStar EdgeSwitch B BGP Admin Status...
Page 97 [2] Get BGP Peer Table, then enter the BGP Peer #. Step 10 In order for the new configuration to take effect, you must restart the OptiStar EdgeSwitch. From the main menu follow the path: [3] Configuration → → → → [2] System Information → → → → [7] Reset OptiStar EdgeSwitch Lucent Technologies 365-575-925R1.5...
Page 98: Configuring An Fcip Network Module
The following tutorials describe how to configure the OptiStar EdgeSwitch for tunneling over IP between Fibre Channel over IP (FCIP) Network Modules. • How to set up IP addresses on an OptiStar EdgeSwitch with one or more FCIP Network Modules (see Section 4.8.1)
Page 99: How To Access The Cli For An Fcip Network Module
Section 4.2.1.1 for additional help). If you are logged on to the OptiStar EdgeSwitch CLI through the serial link, you will access the FCIP Network Module CLI through the Serial Proxy menu item. From the OptiStar EdgeSwitch main menu, follow the path: [4] Administration →...
Page 100: How To Set Passwords For An Fcip Network Module
FCIP Network Module. There is no method for changing the passwords on all modules at once; each FCIP Network Module must be set individually. It is recommended that you change the passwords on all of the FCIP Network Modules on the OptiStar EdgeSwitch. Step 1 Access the CLI for the FCIP Network Module for which you would like to change the password(s).
Page 101: How To Set The Date And Time For An Fcip Network Module
OptiStar EdgeSwitch Configuration 4.8.4 How to Set the Date and Time for an FCIP Network Module Step 1 Access the CLI for the FCIP Network Module for which you would like to set the date and/or time. (see Section 4.8.2, entitled “How to Access the CLI for an FCIP Network Module”...
Page 102: How To Reset An Fcip Network Module
- To reboot, from the OptiStar EdgeSwitch main menu, follow the menu path: [3] Configuration → → → → [2] System Information → → → → [7] Reset OptiStar EdgeSwitch To reset the FCIP Network Module by disabling and then reenabling the FCIP Network Module: - Exit out of the FCIP Network Module CLI by typing logout (versus exit) at the root menu.
Page 103: Example Fcip Tunnel Configuration For 2 Optistar Edgeswitches
OptiStar EdgeSwitch Configuration Step 5 Next go to the CLI main menu for the second OptiStar EdgeSwitch and repeat steps (3) and (4) for the second OptiStar EdgeSwitch. Step 6 Next you are ready to set up routing between the two OptiStar EdgeSwitches. The routing can be set up via static route entry or via one of the following protocols: RIP, OSPF, BGP4.
Page 104 OptiStar EdgeSwitch A to the 2nd port on the Gigabit Ethernet Network Module of OptiStar EdgeSwitch B (i.e. Port 1 of OptiStar EdgeSwitch A is connected to Port 6 of OptiStar EdgeSwitch B). These two ports should therefore be in the same subnet. Since we configured Port 1 of OptiStar EdgeSwitch A in the subnet 192.168.3.0/24, let us assume an IP address of 192.168.3.200 for Port 6...
Page 105 Set up Routing using Static Routes In this example, routing will be set up via static route entry for each OptiStar EdgeSwitch as follows: To set the static route for OptiStar EdgeSwitch A, from the main menu follow the path: [3] Configuration →...
Page 106: Setting Up Wwn Zoning
SAN for interoperability or application reasons, and optimize the flow of traffic over the network. The OptiStar EdgeSwitch uses WWN Zoning to enable the user to set up logical groupings within the Fibre Channel SAN fabric. WWN (World Wide Name) zoning uses the World Wide N_Port_Names (WWPNs) from the name server in the switches to either allow or block access to particular WWNs in the fabric.
Page 107: Enforcement Of Zoning Changes
OptiStar EdgeSwitch Configuration • Configuration of WWN zoning goes from the top down: Zone Sets, Zones, then Members. The higher-order object must be created before the lower-order object. Thus, at least one Zone Set must exist before a Zone can be defined, and both a Zone Set and a Zone must exist before a Member, or WWPN, can be defined.
Page 108 Zones Sets will successfully merge into a new enforced Zone Set on both switches. The enforced Zone Set “Backup” consists of the Zone “UNIX” from Switch A and the Zones “NT” and “MAC” from Switch B. Lucent Technologies 4 - 4 6 365-575-925R1.5...
Page 109: Joining Zoned Fabrics
OptiStar EdgeSwitch Configuration If active Zone Sets are not compatible, the ports connecting the affected switches go into the “Isolated E_Port” state and the switches no longer communicate with each other. Examples of a Failed Zone Merge Operations Active Zone Set (in Flash) Enforced Zone Set (in Temp.
Page 110: How To Configure & Activate Wwn Zoning On The Optistar Edgeswitch
Zone Set to update other switches on the fabric so that all switches have a permanent record of the enforced Zone Set. 4.10.2 How to Configure & Activate WWN Zoning on the OptiStar EdgeSwitch Step 1...
Page 111 OptiStar EdgeSwitch Configuration Step 5 Add Members to the Zone(s) using one of the following three methods: Method 1 To select from World Wide N_Port_Names within the fabric (from the zone menu config/zone/wwn/zone): madd Example: (config/zone/wwn/zone)>madd Item Member Identifier 21 00 00 20 37 C6 E4 BD Enter item from list to select member (Enter 0 to exit, r to repeat list, or <CR>...
Page 112: Exporting/Importing The Optistar Edgeswitch Configuration
Configuration File Export utility. This file may then be imported back into an OptiStar EdgeSwitch at a later time using the Configuration File Import utility. The ability to save and import specific OptiStar EdgeSwitch configurations is extremely useful in the following scenarios: •...
Page 113: Import Configuration File
OptiStar EdgeSwitch will be overwritten.) Step 2 Locate the FTP Server on which an EdgeSwitch Configuration file has previously been saved. (For help on exporting the current OptiStar EdgeSwitch configuration to a binary file on an FTP Server, Lucent Technologies 365-575-925R1.5...
Page 114 The IP Address of the FTP Server on which the EdgeSwitch Configuration file is located The directory (if any) in which the EdgeSwitch Configuration file is saved. The file name of the binary file containing the current OptiStar EdgeSwitch configuration. The user name of the authorized user for the FTP Server.
Page 115: Chapter 5 Detailed Optistar Edgeswitch Cli Reference Guide
Detailed OptiStar EdgeSwitch CLI Reference Guide CHAPTER 5 Detailed OptiStar EdgeSwitch CLI Reference Guide Lucent Technologies 365-575-925R1.5 5 - 1 Issue 1, April 2002...
Page 116: Operational Information & Status
Utilities The following section shows the detailed menu flow in the CLI and gives key MIB variable descriptions. Once the OptiStar EdgeSwitch is booted up, you should see the Main Menu as follows: OptiStar EdgeSwitch Main Menu F3 or .. (Exit) 1) Operational Information &...
Page 117: System Information
5.1.1.1 System General Information Menu Path: [1] Operational Information & Status → [1] System Information → [1] System General Information Description: This menu item displays general information about the OptiStar EdgeSwitch system, as shown in the following example screen: System Description OPTISTAR EDGESWITCH...
Page 118: System Firmware Information
Check to make sure the power supply is inserted all the way into the chassis and that it is seated correctly. Check the power cable in the back of the OptiStar EdgeSwitch to make sure it is properly connected. If the power supply is correctly inserted and the cable is properly connected, power down the OptiStar EdgeSwitch and reinsert the power module.
Page 119: Number Of Fault System Resets
→ [1] 10/100BaseT Port Parameters Description: Displays basic parameters about the 10/100BaseT Port on the OptiStar EdgeSwitch, including Interface Type, Network Type, Interface Flags, Port Speed, IP address and Subnet Mask, MAC Address, Admin Status, Physical Link Status and Operational Status. Also displays operational parameters such as MTU, MRU, Duplex Mode (Full Duplex/Half Duplex) and Auto Negotiation (Enabled/Disabled).
Page 120: Switching Port Parameters
[1] Operational Information & Status → [2] Hardware Status → [6] Fan Status Description: This menu item enables the user to view the status of each of the 4 fans on the OptiStar EdgeSwitch. 5.1.2.7 Power On Self Test (POST) Results Menu Path: [1] Operational Information &...
Page 121: Host Module Post Results
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.1.2.7.1 Host Module POST Results Menu Path: [1] Operational Information & Status → [2] Hardware Status → [7] POST Results → [1] Host Module POST Results Description: This menu item shows the POST results for the following tests:...
Page 122: Ip Parameters
The console port and the management port cannot be grouped. For a tutorial on bridging and port mapping, see Section 4.5.2 entitled “How to Set Up IP Addresses on the OptiStar EdgeSwitch with Bridging”. Module Number...
Page 123: Switching Ports Ip Address
This read-only table shows the current IP address and corresponding subnet mask for each switching port on the OptiStar EdgeSwitch. To modify the parameters on this screen, from the main menu follow the path: [3] Configuration Æ [4] IP Parameters Æ [3] Set Switching Port IP Address and MASK 5.1.5 BOOTP/TFTP Parameters...
Page 124: Community Name Information
5.4.3.6. 5.1.7 Routing Information Sections 5.1.7.1 through 5.1.7.5 enable the user to view routing information for the OptiStar EdgeSwitch, including the routing table, static route information, and the current parameters for each routing protocol (RIP, OSPF and BGP4). 5.1.7.1 Routing Table Menu Path: [1] Operational Information &...
Page 125: Static Routes
[1] Operational Information & Status → [7] Routing Information → [2] Static Routes Description: This read-only table shows the static route entries for the OptiStar EdgeSwitch. To add a static route, from the main menu follow the path: [3] Configuration → [6] Routing Configuration → [1] Set Static Route To delete a static route, from the main menu follow the path: [3] Configuration →...
Page 126: Rip Route Table
[1] Operational Information & Status → [7] Routing Information → [4] OSPF Parameters → [1] Get OSPF Status Description: This read-only screen shows the current OSPF status for the OptiStar EdgeSwitch, including whether running (Enabled/Disabled), OSPF Version, Router Id, AS border support (Enabled/Disabled), and TOS support (Enabled/Disabled).
Page 127: Current Ospf Area Status
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.1.7.4.3 Current OSPF Area Status Menu Path: [1] Operational Information & Status → [7] Routing Information → [4] OSPF Parameters → [3] Current OSPF Area Status Description: When this option is selected, a table is displayed that shows all the valid area ID’s that are currently present.
Page 128: Get Bgp Peer Table
This read-only screen shows the OSPF Internal Subnet Table. To add or delete entries to the OSPF Internal Subnet Table, from the main menu follow the path: [3] Configuration → [6] Routing Configuration → [7] Set BGP4 Parameters → [4] Configure OSPF Internal Subnets Lucent Technologies 5 - 1 4 365-575-925R1.5 Issue 1, April 2002...
Page 129: Get Network, Multi-Exit-Discriminator Table
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.1.7.5.5 Get Network, Multi-Exit-Discriminator Table Menu Path: [1] Operational Information & Status → [7] Routing Information → [5] BGP4 Parameters → [5] Get Network, Multi-Exit-Discriminator Table Description: This read-only screen shows the Network, Multi-Exit-Discriminator Table. To add or delete entries to the Network, Multi-Exit-Discriminator Table, from the main menu follow the path: [3] Configuration →...
Page 130: Get Spanning Tree Protocol Bridge Parameters
[1] Operational Information & Status → [8] Spanning Tree Protocol → [2] Get STP Port Parameters Description: When this option is selected, the STP Parameters for each switching port on the OptiStar EdgeSwitch are displayed, as in the following example:...
Page 131: Static Forward Database Table
FCIP Network Module IP address and subnet mask information for each FCIP Network Module on the local OptiStar EdgeSwitch. The maximum size of the table is four, since there can be a maximum of four FCIP Network Modules in each OptiStar EdgeSwitch. To configure (add) new FCIP Network Module IP addresses, go to the Add Local FCIP Network Module screen (see Section 5.3.9.1...
Page 132: Remote Fcip Network Module Ip Parameters
Name of field Possible Values Definition FCIP Network Integer from 1-4 Number of the slot on the OptiStar EdgeSwitch that contains Module Number the FCIP Network Module. IP Address Valid FCIP The FCIP Network Module IP address assigned to the FCIP Network Module Network Module.
Page 133: Fcip Network Module Connection Status
FCIP Network Modules. FCIP Network local/remote Shows whether the FCIP Network Module belongs to the local Module Location OptiStar EdgeSwitch or a remote OptiStar EdgeSwitch. Lucent Technologies 365-575-925R1.5 5 - 1 9 Issue 1, April 2002...
Page 134: Port Statistics Tasks
[2] Port Statistics → [3] Switching Port Statistics → Enter Module Number (1-4): → Enter Port Number (1-2): Description: This read-only table shows a number of key statistics (measured by Received and Transmit packet sizes) for the selected switching port. Lucent Technologies 5 - 2 0 365-575-925R1.5 Issue 1, April 2002...
Page 135: Configuration Tasks
Once you have verified that the TFTP Server IP Address is entered correctly, then answer y (yes) or n (no) as to whether you want to update the firmware through TFTP. The OptiStar EdgeSwitch will need to be rebooted for these changes to take effect.
Page 136: Set Bootp Status
Description: Enter the file name of the TFTP Firmware. This file is located on the OptiStar EdgeSwitch CD or on the Lucent Website. This file should then be copied to your TFTP server. Note: If applicable, preface the file name with the directory path indicating the file’s location on your TFTP server.
Page 137: Set System Location
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.3.2.2 Set System Location Menu Path: [3] Configuration → [2] System Information → [2] Set System Location Description: Enter the system location. 5.3.2.3 Set System Contact Menu Path: [3] Configuration → [2] System Information → [3] Set System Contact Description: Enter the system contact.
Page 138: Reset Optistar Edgeswitch
Menu Path: [3] Configuration → [2] System Information → [7] Reset OptiStar EdgeSwitch Description: Enter y (yes) to reset the OptiStar EdgeSwitch. CAUTION: If you enter yes, the EdgeSwitch will be reset. 5.3.3 Port Parameters Sections 5.3.3.1 through 5.3.3.3 enable the user to set and modify parameters for each port type on the OptiStar EdgeSwitch.
Page 139: Set Console Port Speed
Detailed OptiStar EdgeSwitch CLI Reference Guide Description: When this menu item is selected, the following screen will be displayed, showing the default parameters for the console port: Console port default parameters 1. Port Speed :38400 bits/sec 2. Maximum Transmission Unit :1500 Bytes 3.
Page 140: Set Switching Port Parameters
Enter a number from the Switching Port Parameters menu to go to the corresponding category. For sections 5.3.3.3.1 through 5.3.3.3.7, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect. 5.3.3.3.1 Set Switching Port with Default Parameters Menu Path: [3] Configuration →...
Page 141: Set Auto Negotiation Mode For Switching Port
Detailed OptiStar EdgeSwitch CLI Reference Guide Description: When this menu item is selected, the following screen will be displayed, showing the Scrambling Mode options for the selected switching port. This menu item applies only to OC/STM modules. Scrambling Mode 1. Post Scrambling 2.
Page 142: Set Maximum Receive Unit For Switching Port
OC or STM module. If the module is either OC-12c or OC-48c, enter 1 to set the Framer Mode to SONET. If the module is either STM-4c or STM-16c, enter 2 to set the Framer Mode to SDH. The default value is SONET. Lucent Technologies 5 - 2 8 365-575-925R1.5...
Page 143: Set Crc Mode
The following 2 sections enable the user to set the IP address and subnet mask for the 10/100BaseT port. For sections 5.3.4.1.1 and 5.3.4.1.2, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect. 5.3.4.1.1 Set 10/100BaseT IP Address Menu Path: [3] Configuration →...
Page 144: Set Console Port Ip Address
Description: This menu item enables the user to enter the IP address for each Switching port on the OptiStar EdgeSwitch. First enter the number of the module (from 1-4) to which the port belongs, then enter the port number (1 or 2). Refer to...
Page 145: Port Mapping
Description: This menu item enables the user to enter the subnet mask for each Switching port on the OptiStar EdgeSwitch. First enter the number of the module (from 1-4) to which the port belongs, then enter the port number (1 or 2). Refer to...
Page 146: Delete Static Route
Sections 5.3.6.5.1 and 5.3.6.5.2 enable the user to set parameters for the RIP routing protocol. For these sections, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect. 5.3.6.5.1 Set RIP General Parameters The following 7 sections enable the user set general parameters for RIP.
Page 147 Detailed OptiStar EdgeSwitch CLI Reference Guide 5.3.6.5.1.1 Configure RIP with Default Parameters Menu Path: [3] Configuration → [6] Routing Configuration → [5] Set RIP Parameters → [1] Set RIP General Parameters → [1] Configure RIP with default parameters Description: When this option is selected, the following screen will be displayed:...
Page 148 [3] Configuration → [6] Routing Configuration → [5] Set RIP Parameters → [1] Set RIP General Parameters → [5] Border gateway filtering Description: When this option is selected, the following screen will be displayed: Border Gateway filtering 1. ENABLE 2. DISABLE Enter choice (1-2): Lucent Technologies 5 - 3 4 365-575-925R1.5 Issue 1, April 2002...
Page 149: Set Rip Interface Status
5.3.6.6 Set OSPF Parameters Sections 5.3.6.6.1 through 5.3.6.6.4 enable the user to set parameters for the OSPF routing protocol. For these sections, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect. Lucent Technologies 365-575-925R1.5 5 - 3 5...
Page 150: Configure Ospf With Default Parameters
[3] Configuration → [6] Routing Configuration → [6] Set OSPF Parameters → [2] General Group → [3] AS border router Description: AS border router 1. Yes 2. No Enter choice (1-2): Lucent Technologies 5 - 3 6 365-575-925R1.5 Issue 1, April 2002...
Page 151: Interface Group
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.3.6.6.2.4 OSPF TOS Support Menu Path: [3] Configuration → [6] Routing Configuration → [6] Set OSPF Parameters → [2] General Group → [4] TOS support Description: This menu item enables the user to enable/disable TOS support.
Page 152: Set Bgp4 Parameters
5.3.6.7 SET BGP4 Parameters Sections 5.3.6.7.1 through 5.3.6.7.7 enable the user to set parameters for the BGP4 routing protocol. For these sections, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect. Lucent Technologies 5 - 3 8 365-575-925R1.5...
Page 153: Set Bgp4 General Parameters
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.3.6.7.1 Set BGP4 General Parameters Menu Path: [3] Configuration → [6] Routing Configuration → [7] Set BGP4 Parameters → [1] Set BGP4 General Parameters Description: [1] BGP Admin Status [2] Enter BGP Identifier (x.x.x.x)
Page 154: Configure Ospf External Subnets
→ [3] Configure OSPF External Subnets → [2] Delete OSPF External Subnet Description: Enter Network Address Enter Network Mask 5.3.6.7.4 Configure OSPF Internal Subnets The following 2 sections enable the user add or delete OSPF internal subnets. Lucent Technologies 5 - 4 0 365-575-925R1.5 Issue 1, April 2002...
Page 155: Configure Network Multi-Exit-Discriminator Pair
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.3.6.7.4.1 Add OSPF Internal Subnet Menu Path: [3] Configuration → [6] Routing Configuration → [7] Set BGP4 Parameters → [4] Configure OSPF Internal Subnets → [1] Add OSPF Internal Subnet Description: Enter Network Address Enter Network Mask 5.3.6.7.4.2 Delete OSPF Internal Subnet...
Page 156: Configure Bgp4 Filter Tags
[3] Configuration → [6] Routing Configuration → [7] Set BGP4 Parameters → [7] Configure OSPF Metric to BGP Metric Map → [1] Add OSPF Metric to BGP Metric Description: Enter OSPF Metric Enter BGP Metric Lucent Technologies 5 - 4 2 365-575-925R1.5 Issue 1, April 2002...
Page 157: Spanning Tree Protocol
STP State, Bridge Priority, Bridge Max Age, Bridge Hello Time and Bridge Forward Delay. For these sections, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect. 5.3.7.1.1 Configure Spanning Tree Bridge with Default Parameters Menu Path: [3] Configuration →...
Page 158: Set Spanning Tree Protocol Bridge Priority
The following 4 sections enable the user to set various parameters for the Spanning Tree Port, including default parameters, Port State, Port Priority and Port Path Cost. For these sections, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect.
Page 159: Configure Spanning Tree Protocol Port With Default Parameters
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.3.7.2.1 Configure Spanning Tree Protocol Port with Default Parameters Menu Path: [3] Configuration → [7] Spanning Tree Protocol → [2] Set Spanning Tree Port Parameters → [1] Configure STP ports with default parameters Description:...
Page 160: Set Static Forwarding Database Entry
The following 2 sections enable the user to add or delete entries to the static forwarding database. For these sections, the OptiStar EdgeSwitch will need to be rebooted for the changes to take effect. 5.3.8.1.1 Add Static Forwarding Database Entry Menu Path: [3] Configuration →...
Page 161: Add Local Fcip Network Module
(which is the FCIP Network Module’s internal IP address) for all FCIP Network Modules in the local OptiStar EdgeSwitch. When this option is selected from the FCIP Network Module Configuration menu, the following prompts will be displayed in succession: Enter the FCIP Network Module Number (1-4): To configure the FCIP Network Module, enter the number of the slot into which the module was inserted.
Page 162: Add Remote Fcip Network Module
The Delete Remote FCIP Network Module menu item allows the user to delete information about remote FCIP Network Modules from the local OptiStar EdgeSwitch. When this option is selected from the FCIP Network Module Configuration menu, the following prompts will be displayed in succession: Enter the IP Address of Remote FCIP Network Module: Enter the FCIP Network Module IP address of the remote FCIP Network Module.
Page 163: Administration Tasks
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.4 Administration Tasks When this option is selected, the following sub menu will be displayed: Administration F1 (Main Menu) F2 or .. (Previous Menu) F3 (Exit) [1] Authentication Information (For help on this item, go to Section 5.4.1 on page...
Page 164: Modify Administrator User Name And Password
[4] Administration → [3] SNMP Configuration → [1] Set SNMP Trap Interval Description: The menu item enables the user to set the interval (in centiseconds) at which SNMP traps will be sent to the management station. Lucent Technologies 5 - 5 0 365-575-925R1.5 Issue 1, April 2002...
Page 165: Add Nms Entry
[4] Administration → [3] SNMP Configuration → [2] Add NMS Entry Description: This menu item enables the user to add an NMS station for the OptiStar EdgeSwitch by entering the IP address of the management station. The Community Mode field (also referred to as Access Mode) enables the user to assign either Read-Write(1) or Read-Only(2) access to the OptiStar EdgeSwitch.
Page 166: Modify Trap Administration Status
Note: To view the current state assigned to a particular trap type, from the main menu follow the path: [1] Operational Information & Status → [6] SNMP Agent Parameters → [4] Get SNMP Trap Administration Status For help on viewing trap status, see Section 5.1.6.4. Lucent Technologies 5 - 5 2 365-575-925R1.5 Issue 1, April 2002...
Page 167: Accessing The Fcip Network Module Cli - Serial Proxy
[4] Administration → [5] FCIP Network Module CLI – Telnet Proxy If you are logged on to the OptiStar EdgeSwitch through the serial link, you will access the FCIP Network Module CLI through the Serial Proxy menu item. Please refer to Section 5.4.4...
Page 168: User Management
8 alpha-numeric characters in length. The user should be instructed to change this password to their own permanent login password once they access the system. Contact Name Enter a name that is a maximum of 16 alphanumeric characters. Lucent Technologies 5 - 5 4 365-575-925R1.5 Issue 1, April 2002...
Page 169: Delete User
Login UserName of the user to be removed. Note: Only the Admin User can not be removed. Once a user is deleted, the OptiStar EdgeSwitch will not recognize their Login UserName and that user will no longer have access to the system.
Page 170: Modify User's Permission
Note: The Admin User’s password can not be reset with this menu item. For help in resetting the Admin User password, see Section 5.4.1.2). Only the Admin User can reset the Admin User password. Lucent Technologies 5 - 5 6 365-575-925R1.5 Issue 1, April 2002...
Page 171: Utilities
Detailed OptiStar EdgeSwitch CLI Reference Guide 5.5 Utilities When this option is selected, the following sub menu will be displayed: Utilities F1 (Main Menu) F2 or .. (Previous Menu) F3 (Exit) [1] Ping Utility (For help on this item, go to Section 5.5.1 on page...
Page 172: Bgp Debug
Enter the correct number to enable (or disable) the BGP Debug utility. You should now see the following message: BGP Debug Prints Enabled (Disabled) Press Enter to Continue… Note: This menu item is not available via Web-based Management. Lucent Technologies 5 - 5 8 365-575-925R1.5 Issue 1, April 2002...
Page 173: Ospf Debug
Name of field Possible Values Definition Slot Slot Number Domain Hexadecimal The Fibre Channel domain to which the OptiStar EdgeSwitch (values x01-xEF) has been assigned. IP Address Valid FCIP The FCIP Network Module IP address of the reachable FCIP Network Module...
Page 174: Local Fcip Network Module State
[5] Utilities → [6] Clear EdgeSwitch Configuration Description: Enter y (yes) to clear the current OptiStar EdgeSwitch configuration values. Enter n (no) to abort the clear operation. WARNING: Many key parameters will be deleted once the current configuration is cleared. If needed, either...
Page 175: Debug Mode Enable
[5] Utilities → [8] EdgeSwitch Configuration Import/Export Description: The following 8 sections enable a user to export the current OptiStar EdgeSwitch configuration to a file, as well as import a file with configuration settings into the OptiStar EdgeSwitch. The export command will write all...
Page 176: Edgeswitch Configuration Server Ip Address
This menu item enables the user to enter the User Name of an authorized user on the FTP Server. Once the user name is entered, the user will also be prompted to enter a password. For help in changing the password at a later time, see Section 5.5.8.6. Lucent Technologies 5 - 6 2 365-575-925R1.5 Issue 1, April 2002...
Page 177: Edgeswitch Configuration Server Password
[5] Utilities → [8] EdgeSwitch Configuration Import/Export → [7] Export Binary EdgeSwitch Configuration to Server Description: Enter y at the prompt if you would like to export the current OptiStar EdgeSwitch configuration to the FTP server. WARNING: Make all desired configuration changes before exporting the configuration. Once you have saved the current configuration to a binary file, do not edit the file.
Page 178 THIS PAGE IS INTENTIONALLY LEFT BLANK Lucent Technologies 5 - 6 4 365-575-925R1.5 Issue 1, April 2002...
Page 179: Chapter 6 Detailed Fcip Network Module Cli Reference Guide
Detailed FCIP Network Module CLI Reference Guide CHAPTER 6 Detailed FCIP Network Module CLI Reference Guide Lucent Technologies 365-575-925R1.5 6 - 1 Issue 1, April 2002...
Page 180 Back out of current sub menu (allows the user to navigate back to the previous menu level) root Go back to the FCIP Network Module root menu help Display help Lucent Technologies 6 - 2 365-575-925R1.5 Issue 1, April 2002...
Page 181: Configure Switch Settings
7) reset_led - Reset fault LED (For help on this item, go to Section 6.1.2.7 on page 6-8) Enter a number from the config/event menu to go to the corresponding category. Lucent Technologies 365-575-925R1.5 6 - 3 Issue 1, April 2002...
Page 182: General Description
Event Log Severity level. 6.1.2.3 Show Event Log Menu Path: 1) config → 2) event → 3) log Shortcut Command: At the root menu, type config event log Lucent Technologies 6 - 4 365-575-925R1.5 Issue 1, April 2002...
Page 183 • Description – this column contains the Ref number (in brackets), which is the vendor’s or MIB’s unique identification of this event string , followed by the event description. Lucent Technologies 365-575-925R1.5 6 - 5 Issue 1, April 2002...
Page 184: Set Event Log Severity Level
At the root menu, type config event led_sev #, where # represents the desired Fault LED Severity level number (see available options in the Description section below). Shortcut Example: >config event led_sev 2 Lucent Technologies 6 - 6 365-575-925R1.5 Issue 1, April 2002...
Page 185: Clear Event Log
FCIP Network Module). The FCIP Network Module will continue to generate event messages as they occur. Do you wish to continue (Yes / No): [N] Press the <Enter> key to keep the event messages, or type a Y, then press the <Enter> key to clear the log. Lucent Technologies 365-575-925R1.5 6 - 7...
Page 186: Reset Fault Led
SAN for interoperability or application reasons, and optimize the flow of traffic over the network. The OptiStar EdgeSwitch uses WWN Zoning to enable the user to set up logical groupings within the Fibre Channel SAN fabric. Port Zoning is not supported on the OptiStar EdgeSwitch.
Page 187: Set Port Zoning Parameters
Shortcut Command: At the root menu, type config zone port Description: This menu item and the related sub menus are not supported on the OptiStar EdgeSwitch. 6.1.3.3 Set WWN Zoning Parameters Menu Path: 1) config → 3) zone → 3) wwn...
Page 188: Show Other Zoning Information
6.1.3.3.4 Configure WWN Zone Sets Menu Path: 1) config → 3) zone → 3) wwn → → → → 4) zoneset Shortcut Command: At the root menu, type config zone wwn zoneset Lucent Technologies 6 - 1 0 365-575-925R1.5 Issue 1, April 2002...
Page 189 (A zoning entry also exists for each mapping of Zone to Zone Set and Member to Zone.) • The OptiStar EdgeSwitch Release 1.5 supports up to 20,000 zoning entries. For example, the switch can hold 20 Zone Sets, each with 9 Zones, which each contain 100 Members. Under this scenario, 18,200 entries are written to Flash (20 + [20 * 9] + [20 * 9 * 100]).
Page 190 This menu item enables the user to create an empty Zone Set with the name specified. A Zone Set must be created before any zones or members can be defined. add “ZoneSetName”, (where ZoneSetName is the name of the empty Zone Set) Example: (config/zone/wwn/zoneset)>add “Backup” Lucent Technologies 6 - 1 2 365-575-925R1.5 Issue 1, April 2002...
Page 191 “ZoneSetName” (where “ZoneSetName” is the name of the Zone Set) Enter a “Y” for yes in the brackets for each zone to be added to the Zone Set. Lucent Technologies 365-575-925R1.5 6 - 1 3 Issue 1, April 2002...
Page 192 This menu command deactivates the current active zone set. Since only one zone set can be active in the fabric at any given time, this command does not need an argument. Once you have entered this command, press the Lucent Technologies 6 - 1 4 365-575-925R1.5...
Page 193: Configure Wwn Zones
(an object being a Zone Set, Zone, or Member), you may enter just the command. If the required object names are not specified when the command is entered, then you are prompted either for the desired name or for selection of one or more objects from a list of those available. Lucent Technologies 365-575-925R1.5 6 - 1 5...
Page 194 1) config → 3) zone → 3) wwn → → → → 5) zone → → → → 4) zdel Shortcut Command: At the root menu, type config zone wwn zone zdel Lucent Technologies 6 - 1 6 365-575-925R1.5 Issue 1, April 2002...
Page 195 (config/zone/wwn/zone - zone)> 1 Method 2 To manually enter World Wide N_Port_Names: madd “WWPN” “ZoneName” (where WWPN is the World Wide N_Port_Name and ZoneName is the name of the Zone) Lucent Technologies 365-575-925R1.5 6 - 1 7 Issue 1, April 2002...
Page 196 11 22 33 44 55 66 77 88 [N]: FF EE DD CC BB AA 99 88 [Y]: Storing zone set information... Do you wish to continue (Yes / No): [Y] Lucent Technologies 6 - 1 8 365-575-925R1.5 Issue 1, April 2002...
Page 197: Set Port Parameters
This is followed by the currently selected port, which is shown in the Current Port Number field. The config/port sub menu will then be displayed. Lucent Technologies 365-575-925R1.5 6 - 1 9...
Page 198 G_Port: Generic port; can act as either F_Port or E_Port. Valid for Fabric and Public/Private Communication Mode. Stealth Loop: This option is not supported on the OptiStar EdgeSwitch. Module The type of GBIC module inserted into the FCIP Network Module switch port.
Page 199: Show Current Port Settings
Note: Type 4 (stealthLoop) is not supported on the OptiStar EdgeSwitch. In the above example, the port being displayed is Port 1. All subsequent port operations will be performed on this port. If the user decides to set another port, first they must choose option 5 to change the FCIP Network...
Page 200: Set Port Type
In this example, the current port type is [5] autoDetect. Note: Option [4] stealthLoop is not supported on the OptiStar EdgeSwitch. However, even though Option [4] stealthLoop may not be set as the selected port type, in certain cases the FCIP port will report itself as a stealthLoop port type. For example, when...
Page 201: Set Port Name
Press the <Enter> key to keep the existing system name, or enter a new name after the equal sign, then press the <Enter> key. The display will show OK, indicating the new name has been accepted. Lucent Technologies 365-575-925R1.5 6 - 2 3...
Page 202: Set Port Number
In this example, the port will accept Fabric services. Press the <Enter> key to keep the current PRLI setting, or enter a new setting after the equal sign, then press the <Enter> key. The display will show OK, indicating the new setting has been accepted. Lucent Technologies 6 - 2 4 365-575-925R1.5...
Page 203: Enable / Disable Fabric Address Notification
This prevents the other ports from starving out for data frames or holding too much in their data buffers. Lucent Technologies 365-575-925R1.5 6 - 2 5...
Page 204: Set Bb Credit For Port
6.1.4.10 Set Maximum Receive Buffer Size Menu Path: 1) config → 4) port → 10) mrbs Shortcut Command: At the root menu, type config port mrbs #, where # is the desired MRBS value. Lucent Technologies 6 - 2 6 365-575-925R1.5 Issue 1, April 2002...
Page 205: Configure Advanced Port Settings
12) speed - Set the port speed (For help, go to Section 6.1.4.11.12 on page 6-34) Enter a number from the config/port/advanced menu to go to the corresponding category. Lucent Technologies 365-575-925R1.5 6 - 2 7 Issue 1, April 2002...
Page 206: General Description
ALTOV LPTO RXTHRSH TXTHRSH SPEED 2112 1000 120000 2112 1000 120000 Current Port Number: 1 Legend for the enumerated column (SPEED) on the Port Configuration Table: SPEED Invalid oneGig Lucent Technologies 6 - 2 8 365-575-925R1.5 Issue 1, April 2002...
Page 207: Set Max Receive Buffer Payload Size
At the root menu, type config port advanced tbs #, where # is the desired Maximum Transmit Buffer Size. Shortcut Example: > config port advanced tbs 16 This example sets the Maximum Transmit Buffer Size to 16. Lucent Technologies 365-575-925R1.5 6 - 2 9 Issue 1, April 2002...
Page 208: Set Error Detection Timeout Value
Next, the current EDTOV setting is displayed in brackets (in this example the EDTOV is set to 10): EDTOV [2000] = To accept the current EDTOV setting, press the <Enter> key. To change the setting, first type in the new value then press the <Enter> key. Lucent Technologies 6 - 3 0 365-575-925R1.5 Issue 1, April 2002...
Page 209: Set Resource Allocation Timeout Value
To accept the current RATOV setting, press the <Enter> key. To change the setting, first type in the new value then press the <Enter> key. For example, to change the RATOV value to 20000, type 20000 at the prompt: RATOV [10000] =20000 <Enter> Lucent Technologies 365-575-925R1.5 6 - 3 1 Issue 1, April 2002...
Page 210: Set Loop Initialization Timeout Value
At the root menu, type config port advanced lpto #, where # is the desired Loop Connection Timeout Value. Shortcut Example: >config port advanced lpto 100 This example sets the Loop Connection Timeout Value to 100 milliseconds. Lucent Technologies 6 - 3 2 365-575-925R1.5 Issue 1, April 2002...
Page 211: Set Receive Credit Threshold
At the root menu, type config port advanced txthresh #, where # is the desired Transmit Available Threshold. Shortcut Example: >config port advanced txthresh 100 This example sets the Transmit Available Threshold to 100. Lucent Technologies 365-575-925R1.5 6 - 3 3 Issue 1, April 2002...
Page 212: Set Port Number
1) config → 4) port → 11) advanced → 12) speed Shortcut Command: At the root menu, type config port advanced speed to view the current Port Speed setting. Lucent Technologies 6 - 3 4 365-575-925R1.5 Issue 1, April 2002...
Page 213: Set Rscn Mode
RSCN [1] = Press the <Enter> key to accept the current RSCN setting, or enter a new value then press the <Enter> key. The display will show OK, indicating the new value has been accepted. Lucent Technologies 365-575-925R1.5 6 - 3 5...
Page 214: Set System Parameters
: 16:34:59 Date : 10/30/2000 Detected Ethernet : eth10half Ethernet Mode : ethAuto Address Mode : Fabric Boot Image : Image 1 Up Time : 0 days, 00:51:40 (hr:min:sec) Lucent Technologies 6 - 3 6 365-575-925R1.5 Issue 1, April 2002...
Page 215: Show System Settings
Press the <Enter> key to keep the existing system name, or enter a new name after the equal sign, then press the <Enter> key. The display will show OK, indicating the new name has been accepted. Lucent Technologies 365-575-925R1.5 6 - 3 7...
Page 216: Set System Time
Press the <Enter> key to keep the existing System Date, or enter a new date value after the equal sign, then press the <Enter> key. The display will show OK, indicating the new date has been accepted. Lucent Technologies 6 - 3 8 365-575-925R1.5...
Page 217: Set System Contact
1) config → 5) system → 7) ethmode Shortcut Command: At the root menu, type config system ethmode Description This menu item is not supported on the OptiStar EdgeSwitch. 6.1.5.8 Set System Location Menu Path: 1) config → 5) system → 8) location Shortcut Command: At the root menu, type config system location “abc”, where abc is the desired System Location.
Page 218: Configure Advanced Settings
7) rcf - Set RCF disruptive mode (For help, go to Section 6.1.5.9.7 on page 6-44) Enter a number from the config/system/advanced menu to go to the corresponding category. Lucent Technologies 6 - 4 0 365-575-925R1.5 Issue 1, April 2002...
Page 219: General Description
1) config → 5) system → 9) advanced → 3) domid Shortcut Command: At the root menu, type config system advanced domid #, where # is the hexadecimal value of the desired Domain ID Lucent Technologies 365-575-925R1.5 6 - 4 1 Issue 1, April 2002...
Page 220: Set The Number Of Private Addresses Per Port
In this example, the number of Private Addresses is set to 64. Press the <Enter> key to keep the current number, or enter a new number after the equal sign, then press the <Enter> key. The display will show OK, indicating the new value has been accepted. Lucent Technologies 6 - 4 2 365-575-925R1.5...
Page 221: Set The Principal Switch Priority
Press the <Enter> key to keep the current Loop Fabric Address setting, or enter a new value then press the <Enter> key. The display will show OK, indicating the new value has been accepted. Lucent Technologies 365-575-925R1.5 6 - 4 3...
Page 222: Set Rcf Disruptive Mode
The trap –Trap destination configurations menu item enables the user to view detailed information about the trap settings on the FCIP Network Module. When this menu item is selected the config/system/trap sub menu will be displayed. Lucent Technologies 6 - 4 4 365-575-925R1.5...
Page 223: Show Current Traps
Failed event occurred; no action required [5] notify Configuration error or abnormal event occurred; no action required [6] info Event occurred; no action required [7] debug Internal message for development [8] mark Message marker Lucent Technologies 365-575-925R1.5 6 - 4 5 Issue 1, April 2002...
Page 224: Set State Of Trap
IP Addr Port RowState 1> 192.168.67.1 Active Enter item from list to delete Trap destination entry Enter 0 to exit, r to repeat list or <CR> to quit = Lucent Technologies 6 - 4 6 365-575-925R1.5 Issue 1, April 2002...
Page 225: Change Passwords
FCIP Network Module must be set individually. It is recommended that you change the passwords on all of the FCIP Network Modules on the OptiStar EdgeSwitch, then perform a reset of the OptiStar EdgeSwitch (see Section 4.8.5) for the password changes to take effect.
Page 226: Set Monitor / Manage Password
FCIP Network Module must be set individually. It is recommended that you change the passwords on all of the FCIP Network Modules on the OptiStar EdgeSwitch, then perform a reset of the OptiStar EdgeSwitch (see Section 4.8.5) for the password changes to take effect.
Page 227: Set License Keys
Menu Path: 1) config → 7) key Shortcut Command: At the root menu, type config key Description This menu item is not supported on the OptiStar EdgeSwitch. 6.1.8 Set Communication Parameters Menu Path: 1) config → 8) com Shortcut Command:...
Page 228: General Description
1) config → 8) com → 3) console Shortcut Command: At the root menu, type config com console Description The Set console mode menu item is not supported on the OptiStar EdgeSwitch. Lucent Technologies 6 - 5 0 365-575-925R1.5 Issue 1, April 2002...
Page 229: General Description
6-51) Enter a number from the config/com/console menu to go to the corresponding category. 6.1.8.3.1 General Description The console – Set console mode menu item is not supported on the OptiStar EdgeSwitch. Example: Power up console mode: Command Note: This parameter determines the power-on mode of the serial port. Changing this parameter may affect the user’s ability to manage the device through the serial port using the Command Line...
Page 230: Set Ethernet Parameters
Description The Set console mode menu item is not supported on the OptiStar EdgeSwitch. This menu item enables the user to determine how the serial port will communicate with other data terminating equipment (Command - DTE) or data communication equipment (SLIP - DCE).
Page 231: Show Current Ethernet Settings
The user must set the Ethernet address to be able to later configure the switch through the CLI. When this menu item is selected, the current IP address is displayed in brackets. Note: Changes to this parameter will take affect on next reset IP Address [192.168.11.73] = Lucent Technologies 365-575-925R1.5 6 - 5 3 Issue 1, April 2002...
Page 232: Set Ethernet Netmask
Press the <Enter> key to keep the current Default Gateway, or enter a new gateway address after the equal sign, then press the <Enter> key. The display will show OK, indicating the new gateway address has been accepted. Lucent Technologies 6 - 5 4 365-575-925R1.5...
Page 233: Set Slip Parameters
At the root menu, type config com slip show Description When this menu item is selected, the current SLIP settings will be displayed. Example: SLIP Address : 192.168.2.129 SLIP Netmask : 255.255.255.0 Lucent Technologies 365-575-925R1.5 6 - 5 5 Issue 1, April 2002...
Page 234: Set Slip Ip Address
Press the <Enter> key to keep the current netmask, or enter a new netmask after the equal sign, then press the <Enter> key. The display will show OK, indicating the new netmask has been accepted. Lucent Technologies 6 - 5 6 365-575-925R1.5...
Page 235: Set Modem Parameters
Detailed FCIP Network Module CLI Reference Guide 6.1.8.6 Set Modem Parameters Note: This menu item and the related sub menus are not supported on the OptiStar EdgeSwitch. When menu item 6) modem – Set modem parameters is selected, the following sub menu will be displayed:...
Page 236: Set Fcip Network Module Operating Mode
When this menu item is selected, the operation mode settings for the switch will be displayed. Example: Address Mode : Fabric (Public/Private) Alt JBOD Add Mode : false Stealth Master : false Lucent Technologies 6 - 5 8 365-575-925R1.5 Issue 1, April 2002...
Page 237: Set Switch Addressing Mode
Shortcut Command: At the root menu, type config mode policy Description This menu item enables the user to set the operating policy on the OptiStar EdgeSwitch. When this menu item is selected, the available options are displayed: Operating Policy Options...
Page 238: Reset The Fcip Network Module
6-73) 13) fspf - Show FSPF table (For help, go to Section 6.3.13 on page 6-73) Enter a number from the show menu to go to the corresponding category. Lucent Technologies 6 - 6 0 365-575-925R1.5 Issue 1, April 2002...
Page 239: General Description
3) show → 2) zones → 2) ports Shortcut Command: At the root menu, type show zones ports Description Note: Port Zoning is not supported on the OptiStar EdgeSwitch. Lucent Technologies 365-575-925R1.5 6 - 6 1 Issue 1, April 2002...
Page 240: Show Wwn Zoning Information
3) show → → → → 2) zones → → → → 3) wwn → → → → 3) senf Shortcut Command: At the root menu, type show zones wwn senf Lucent Technologies 6 - 6 2 365-575-925R1.5 Issue 1, April 2002...
Page 241: Show Other Zoning Parameters
The ports – Show port settings menu item enables the user to view detailed information about the port settings on the FCIP Network Module. When this menu item is selected the show/port sub menu will be displayed. Lucent Technologies 365-575-925R1.5...
Page 242: Show Port Configuration
Note: Type 4 (stealthLoop) is not supported on the OptiStar EdgeSwitch. 6.3.3.3 Show Port Status Menu Path: 3) show → → → → 3) ports → → → → 3) status Shortcut Command: At the root menu, type show ports status...
Page 243: Show General Port Statistics
11 noMedia loopNonparticipate 12 linkDown 13 isolated Note: Det Typ 5 (stealthLoop) is not supported on the OptiStar EdgeSwitch. 6.3.3.4 Show General Port Statistics Menu Path: 3) show → → → → 3) ports → → → → 4) gen_stat...
Page 244: Show Advanced Port Settings
At the root menu, type show ports c2_stat Description When this menu item is selected, the Class 2 Statistics Table will be displayed. Example: Class 2 Statistics Table Port IN_FRM OUT_FRM IN_OCT OUT_OCT DISCARD F_BSY F_RJT Lucent Technologies 6 - 6 6 365-575-925R1.5 Issue 1, April 2002...
Page 245: Show Class 3 Port Statistics
Select y (yes) to continue with clearing the port statistics. 6.3.4 Show System Settings Menu Path: 3) show → → → → 4) system Shortcut Command: At the root menu, type show system Lucent Technologies 365-575-925R1.5 6 - 6 7 Issue 1, April 2002...
Page 246: Show Communication Settings
When this menu item is selected, the Communication settings will be displayed. Example: IP Address : 192.168.11.73 Netmask : 255.255.255.0 Default Gateway : 192.168.11.253 SLIP Address : 192.168.2.129 SLIP Netmask : 255.255.255.0 Modem Init String : ATE0V1Q0 Lucent Technologies 6 - 6 8 365-575-925R1.5 Issue 1, April 2002...
Page 247: Show Key Features And Current Key Status
3) show → → → → 6) keys Shortcut Command: At the root menu, type show keys Description This menu item is not supported on the OptiStar EdgeSwitch. 6.3.7 Show Event Log Menu Path: 3) show → → → → 7) events...
Page 248: Show Firmware Image Information
Image 1 Current Image : Received 10/30/2000 at 11:51:47 Current Image Ver : 03.00 00108 Image 2 Alternate Image : Received 10/16/2000 at 12:52:35 Alternate Image Ver : 03.00 00106 Lucent Technologies 6 - 7 0 365-575-925R1.5 Issue 1, April 2002...
Page 249: Show Device Information
6-72) 5) clear - Clear link statistics (For help, go to Section 6.3.11.5 on page 6-73) Enter a number from the show/link menu to go to the corresponding category. Lucent Technologies 365-575-925R1.5 6 - 7 1 Issue 1, April 2002...
Page 250: General Description
6.3.11.4 Show Link Protocol Statistics Menu Path: 3) show → → → → 11) link → → → → 4) protocol Shortcut Command: At the root menu, type show link protocol Lucent Technologies 6 - 7 2 365-575-925R1.5 Issue 1, April 2002...
Page 251: Clear Link Statistics
3) show → → → → 13) fspf Shortcut Command: At the root menu, type show fspf Description: When this menu item is selected, the FSPF Table will be displayed. Lucent Technologies 365-575-925R1.5 6 - 7 3 Issue 1, April 2002...
Page 252: Access Firmware Options
Power-up Image : Image 1 Image 1 Current Image : vxWorks.dwn Current Image Ver : 03.00 00109 Image 2 Alternate Image : vxWorks.dwn Alternate Image Ver : 03.00 00108 Lucent Technologies 6 - 7 4 365-575-925R1.5 Issue 1, April 2002...
Page 253: Load New Firmware Via Tftp
When this menu item is selected, the following message will be displayed: Start tftp Transfer to m: from host shell. Open a DOS-prompt box on the PC that is connected to the OptiStar EdgeSwitch (e.g. the TFTP server). Type the following command at the DOS prompt: tftp –i <OptiStar EdgeSwitch 10/100BaseT IP address>...
Page 254: Select Alternate Version Of Firmware
At the root menu, type firmware reset Description This menu item is not supported in Release 1.2 of the OptiStar EdgeSwitch. This menu item enables the user to reset the FCIP Network Module. Once you have selected this item, you...
Page 255: Access Diagnostic Features
Section 6.5.2.4 on page 6-79) Enter a number from the diagnostics/system menu to go to the corresponding category. Note: Menu item 3) ethled – Select Ethernet LED behavior is not supported on the OptiStar EdgeSwitch. Lucent Technologies 365-575-925R1.5 6 - 7 7...
Page 256: General Description
The Ethernet LED mode options under this sub menu are not supported on the OptiStar EdgeSwitch. When this menu item is selected, the current Ethernet LED Mode will be displayed, followed by the diagnostics/system sub menu.
Page 257: Reset Switch Settings To Factory Default
6-82) 7) port - Set port number (For help, go to Section 6.5.3.7 on page 6-82) Enter a number from the diagnostics/port menu to go to the corresponding category. Lucent Technologies 365-575-925R1.5 6 - 7 9 Issue 1, April 2002...
Page 258: General Description
At the root menu, type diagnostics port show Description: This menu item shows the current Port Diagnostics table. Example: Port Diagnostics Table Port Beacon State Legend for enumerated columns: Beacon State unknown Lucent Technologies 6 - 8 0 365-575-925R1.5 Issue 1, April 2002...
Page 259: Beacon Port
The display will show OK, indicating the reset has taken place. 6.5.3.5 Send PLOG/PRLI to All Devices on Port Menu Path: 5) diagnostics → 3) port → 5) prli Shortcut Command: At the root menu, type diagnostics port prli Lucent Technologies 365-575-925R1.5 6 - 8 1 Issue 1, April 2002...
Page 260: Set The Operating Mode Of Port
In this example, the port that is being acted upon is Port 1. Press the <Enter> key to keep the current port, or enter a new port number after the equal sign, then press the <Enter> key. The display will show OK, indicating the new setting has been accepted. Lucent Technologies 6 - 8 2 365-575-925R1.5...
Page 261: Clear System Errors
Stack -0: 0x00000000 Stack -1: 0x109FD068 Stack -2: 0x00000000 Stack -3: 0x00000000 Stack -4: 0x00000000 Stack -5: 0x00000000 Stack -6: 0x00000000 Stack -7: 0x00000000 Stack -8: 0x00000000 Stack -9: 0x00000000 Lucent Technologies 365-575-925R1.5 6 - 8 3 Issue 1, April 2002...
Page 262: Read Memory
At the root menu, type diagnostics memshow Description: When this menu item is selected, the maximum available memory block size will be displayed. Example: Max Available Memory Block Size: 5974592 Lucent Technologies 6 - 8 4 365-575-925R1.5 Issue 1, April 2002...
Page 263: Debugging Trace Control
At the root menu, type diagnostics trace list Description: When this menu item is selected, the following module information is displayed: Module mask timer ZDBModule veport router port0 fctl eport zoneManager zoneEnforcer nsdb Lucent Technologies 365-575-925R1.5 6 - 8 5 Issue 1, April 2002...
Page 264: Set Module Trace Mask
Section 6.5.8.2 Shortcut Example: >diagnostics trace set “port0 on” Description: To set the module trace mask, the user must use the shortcut command from the diagnostics/trace menu. Lucent Technologies 6 - 8 6 365-575-925R1.5 Issue 1, April 2002...
Page 265: Chapter 7 Optistar Edgeswitch Maintenance Tasks
OptiStar EdgeSwitch Maintenance Tasks CHAPTER 7 OptiStar EdgeSwitch Maintenance Tasks Lucent Technologies 365-575-925R1.5 7 - 1 Issue 1, April 2002...
Page 266: General Maintenance
Clearing the current OptiStar EdgeSwitch Configuration 7.1 General Maintenance Periodically perform maintenance on your OptiStar EdgeSwitch. Keep components free of dust and other particulate matter. Check fans for reduced airflow caused by dust build-up and clean as necessary. Examine cables and fiber for damage and ensure that airflow requirements have been met. Otherwise, no special maintenance is required.
Page 267: Figure 7-1: Network Module Removal. Note That Release Levers Are Extended
Slowly insert the FCIP Network Module into the slot making sure that the edges of the Module line up with the guides on the chassis. The Module is seated when the front panel of the Module is flush with the front panel of the OptiStar EdgeSwitch. Step 2 Ensure that the release levers on the front edges of the modules are in a closed position (pressed against the front panel).
Page 268: Power Module Replacement
The Fan Module is hot swappable. When removing the Fan Module, work as quickly as you can while the OptiStar EdgeSwitch is still running. To replace, loosen the two thumbscrews on the front panel of the unit where the Fan Module is located. Gently remove the Fan Module by pulling on the handle on the front of the module, taking care to pull straight out of the guide frame.
Page 269: Power Socket Fuse Replacement
Under normal operating conditions you would not need to replace the power socket fuse, however, in the event of a severe power surge occurring in a power circuit providing AC electrical power to the OptiStar EdgeSwitch, it is possible that the fuse may burn out. To change the fuse, locate the compartment at the bottom of the power cord socket on the back of the switch.
Page 270: Installing New Fcip Network Module Firmware
To upload FCIP Network Module firmware using the OptiStar EdgeSwitch 10/100BaseT network connection: Ensure that the OptiStar EdgeSwitch is configured correctly and that the PC NIC card has been configured to be on the same subnet as the OptiStar EdgeSwitch 10/100BaseT port (see Section 4.5).
Page 271 You should now see the following message: Start tftp Transfer to m: from host shell. Step 7 Next, open a DOS-prompt box on the PC that is connected to the OptiStar EdgeSwitch (e.g. the TFTP server). Step 8 Type the following command at the DOS prompt: tftp –i <OptiStar EdgeSwitch 10/100BaseT IP address>...
Page 272: How To Manually Select The Fcip Network Module Firmware Boot Image
OptiStar EdgeSwitch. It is strongly recommended that the same firmware level is maintained for all FCIP Network Modules on an OptiStar EdgeSwitch . Even though it is possible for modules to have different firmware versions, it is not recommended.
Page 273 OptiStar EdgeSwitch Maintenance Tasks Step 5 Once you have cleared the configuration, the BAUD rate will revert to 38400 (the default value). If you would like the baud rate of your terminal server program to be different than the default value of 38400, please change the value now.
Page 274 THIS PAGE IS INTENTIONALLY LEFT BLANK Lucent Technologies 7 - 1 0 365-575-925R1.5 Issue 1, April 2002...
Page 275: Chapter 8 Troubleshooting
Troubleshooting CHAPTER 8 Troubleshooting Lucent Technologies 365-575-925R1.5 8 - 1 Issue 1, April 2002...
Page 276 If replacing the fan tray doesn’t cool the unit down, power it down and contact Lucent for technical. support. See Section 9.1 for contact information. • Check to make sure that the OptiStar EdgeSwitch is in a good location. See Section 3.2 for Rack- Mounting instructions. •...
Page 277 If unrecognizable characters appear, then check the serial port parameters for the correct BAUD rate, parity, data size and number of STOP bits. The first time the OptiStar EdgeSwitch powers ON, it will have the following default parameters: BAUD rate –...
Page 278 FCIP Network Module IP address you assigned is in the same subnet as Port 1 of the FCIP Network Module. For help please refer to the Section 4.8, entitled “Configuring an FCIP Network Module”. Lucent Technologies 8 - 4 365-575-925R1.5 Issue 1, April 2002...
Page 279 • Check to see if the FCIP Network Module is inserted message indicates an error (from the properly into the slot on the OptiStar EdgeSwitch. OptiStar EdgeSwitch main menu, follow • the path (5) Utilities Æ Æ Æ Æ (5) FCIP Network Check to make sure the FCIP Network Module has an assigned IP address.
Page 280 Section 6.1.4.11.6. After changing the Domain ID, an FC • Ensure that the OptiStar EdgeSwitch has been tunnel can not be established between rebooted for the Domain ID to take effect. For help OptiStar EdgeSwitches. rebooting the OptiStar EdgeSwitch, see Section 4.8.5.
Page 281: Chapter 9 Contacting Lucent
Contacting Lucent CHAPTER 9 Contacting Lucent Lucent Technologies 365-575-925R1.5 9 - 1 Issue 1, April 2002...
Page 282: Lucent Technologies Customer Support
Lucent Technologies warrants that during the warranty period the OptiStar EdgeSwitch will operate in accordance with Lucent's standard published documentation accompanying the OptiStar EdgeSwitch. The warranty period for the OptiStar EdgeSwitch is twelve (12) months for hardware and ninety (90) days for software, unless your purchase agreement provides a different warranty.
Page 283: Appendices
Appendices APPENDICES Lucent Technologies 365-575-925R1.5 A P - 1 Issue 1, April 2002...
Page 284: Appendix A: Quickstart Checklist & Planning Worksheet For A Typical Optistar Edgeswitch Configuration
PPENDIX QuickStart Checklist & Planning Worksheet for a Typical OptiStar EdgeSwitch Configuration Step Action to Perform Menu Path Section in the User’s Guide Appendix A Plan your network configuration. A Basic Configuration Worksheet is included at the end of Appendix A to guide you in the planning process.
Page 285 Reboot/Reset the OptiStar [2] System Information → EdgeSwitch. [7] Reset OptiStar… Section 4.1.1 Allow the OptiStar EdgeSwitch to fully boot (this time allow it to AutoBoot instead of getting in to the BootUp Menu). Section 4.3.1 Login in as Admin User (use “optistar”...
Page 286 [5] Utilities → Section 5.5.8 Save the current configuration to a file [8] Config. Import/Export… by setting up the FTP server parameters and then using the Configuration File Export command. Lucent Technologies A P - 4 365-575-925R1.5 Issue 1, April 2002...
Page 287 TFTP Firmware File Name OptiStar Configuration Import/Export Information FTP Server IP Address FTP Server Directory Name (optional) FTP Server File Name User Name for FTP Server User Password for FTP Server Lucent Technologies 365-575-925R1.5 A P - 5 Issue 1, April 2002...
Page 288 Channel Switch as well as each FCIP Network Module must have a unique Domain ID. Static Routes (Optional) Destination IP Address Subnet Mask Gateway IP Address Note: Only if static routing is used. Add additional static routes as needed. Lucent Technologies A P - 6 365-575-925R1.5 Issue 1, April 2002...
Page 289 World Wide Name (WWN) Zoning Complete the following tables to help in planning and configuring WWN Zoning on the OptiStar EdgeSwitch. Copy this page to add additional Zone Sets and Zones. The maximum number of zoning entries allowed on the switch depends on the amount of Flash used for the flash file system.
Page 290: Appendix B: Optistar Edgeswitch Cli Menu Structure
PPENDIX OptiStar EdgeSwitch CLI Menu Structure First Level Menus Operational Information & Status Port Statistics Configuration Administration Utilities Change My Password Second Level Menus 1) Operational Information & Status 1) System Information 2) Hardware Status 3) Port Mapping 4) IP Parameters...
Page 291 3) Config Æ Æ Æ Æ 1) BOOTP/TFTP Æ Æ Æ Æ 1) Enable TFTP to Download Firmware 2) Set BOOTP Status 3) Set TFTP Server IP Address 4) Set TFTP Firmware File Name Lucent Technologies 365-575-925R1.5 A P - 9 Issue 1, April 2002...
Page 292 4) Set System Temperature Threshold 5) Set Time Server IP Address 6) Set System with Default Values 7) Reset OptiStar EdgeSwitch 3) Config Æ Æ Æ Æ 3) Port Parameters Æ Æ Æ Æ 1) Set 10/100BaseT Port Parameters 2) Set Console Port Parameters 3) Set Switching Port Parameters 3) Config Æ...
Page 293 1) Operational Æ Æ Æ Æ 2) Hardware StatusÆ Æ Æ Æ 3) # of Fault Sys Reset -- (no sub menus) 1) Operational Æ Æ Æ Æ 2) Hardware StatusÆ Æ Æ Æ 4) Switching Module Enter Module Number(1-4): Lucent Technologies 365-575-925R1.5 A P - 1 1 Issue 1, April 2002...
Page 294 1) Operational Æ Æ Æ Æ 10) FCIP Network ModuleÆ Æ Æ Æ 3) FCIP Connection Status -- (no sub menus) 2) Port Stats Æ Æ Æ Æ 1) 10/100BaseT Port StatsÆ Æ Æ Æ Æ Æ Æ Æ -- (no sub menus) Lucent Technologies A P - 1 2 365-575-925R1.5...
Page 295 3) Config Æ Æ Æ Æ 2) System Info Æ Æ Æ Æ 6) Set System with Default Values Do you want to configure system with the above default parameters?(y/n) 3) Config Æ Æ Æ Æ 2) System Info Æ Æ Æ Æ 7) Reset OptiStar EdgeSwitch Do you want to Reset the OptiStar(TM) EdgeSwitch(y/n) : 3) Config Æ...
Page 296 4) AdminÆ Æ Æ Æ 1) Auth Info Æ Æ Æ Æ 2) Modify Admin UserName, Pswrd Enter Old Administrator User Name: Enter Old Administrator Password : Enter New Administrator UserName : Enter New Administrator Password : Lucent Technologies A P - 1 4 365-575-925R1.5 Issue 1, April 2002...
Page 297 5) Util Æ Æ Æ Æ 8) ES Import/Export Æ Æ Æ Æ 7) Export Binary ES Config -- (no sub menus) 5) Util Æ Æ Æ Æ 8) ES Import/Export Æ Æ Æ Æ 8) Import Binary ES Config File -- (no sub menus) Lucent Technologies 365-575-925R1.5 A P - 1 5...
Page 298 3) Config Æ Æ Æ Æ 6) Routing Æ Æ Æ Æ 7) Set BGP4Æ Æ Æ Æ 7) Metric 1) Add OSPF Metric to BGP Metric 2) Delete OSPF Metric from BGP Metric Lucent Technologies A P - 1 6 365-575-925R1.5...
Page 299: Appendix C: Fcip Network Module Cli Menu Structure
5) stack - Show stack dump from last detected fault (Example: >stack) 6) read - Read memory 7) memshow - Show available memory space (Example: >memshow) 8) trace - Debugging trace control (Example: >trace) Lucent Technologies 365-575-925R1.5 A P - 1 7 Issue 1, April 2002...
Page 300 2) show - Show current communication settings (Example: >show) 3) console - Set console mode 4) ethernet - Set ethernet parameters 5) slip - Set SLIP parameters 6) modem - Set modem parameters Lucent Technologies A P - 1 8 365-575-925R1.5 Issue 1, April 2002...
Page 301 4) firmware Æ Æ Æ Æ 3) load Æ Æ Æ Æ 1) Verify and Store 2) Abort 4) firmware Æ Æ Æ Æ 4) select Æ Æ Æ Æ [1] Image 1 [2] Image 2 Lucent Technologies 365-575-925R1.5 A P - 1 9 Issue 1, April 2002...
Page 302 [6] info [7] debug [8] mark 1) config Æ Æ Æ Æ 2) event Æ Æ Æ Æ 6) clear_log Æ Æ Æ Æ -- (no sub menus) Lucent Technologies A P - 2 0 365-575-925R1.5 Issue 1, April 2002...
Page 303 10) txthrsh - Set transmit available threshold (Example: >txthresh 100) 11) port - Set port number (Example: >port 3) 12) speed - Set the port speed (Example: >speed twoGig) Lucent Technologies 365-575-925R1.5 A P - 2 1 Issue 1, April 2002...
Page 304 1) config Æ Æ Æ Æ 8) com Æ Æ Æ Æ 6) modem Æ Æ Æ Æ 1) back - Go back 2) show - Show current modem settings (Example: >show) 3) init - Set modem init string (Example: >init ate1v1) Lucent Technologies A P - 2 2 365-575-925R1.5 Issue 1, April 2002...
Page 305 5) diagnostics Æ Æ Æ Æ 3) portÆ Æ Æ Æ 5) prli Æ Æ Æ Æ -- (no sub menus) 5) diagnostics Æ Æ Æ Æ 3) portÆ Æ Æ Æ 6) mode Æ Æ Æ Æ -- (no sub menus) Lucent Technologies 365-575-925R1.5 A P - 2 3 Issue 1, April 2002...
Page 306 5) diagnostics Æ Æ Æ Æ 8) trace Æ Æ Æ Æ 2) list Æ Æ Æ Æ -- (no sub menus) 5) diagnostics Æ Æ Æ Æ 8) trace Æ Æ Æ Æ 3) set Æ Æ Æ Æ -- (no sub menus) Lucent Technologies A P - 2 4 365-575-925R1.5 Issue 1, April 2002...
Page 307: Appendix D: Optistar™ Edgeswitch Specifications
Two redundant, hot-swappable power supplies with automatic failover 200 Watts, 90-132/180-264 Volts AC @ 47-63 Hz, auto-ranging Environmental Operating Temperature 0° to 40°C Requirements Operating Humidity 10-80% non-condensing Lucent Technologies 365-575-925R1.5 A P - 2 5 Issue 1, April 2002...
Page 308 4.19 lb (1.9 kg) Weight, OC-48c/STM-16c 1.02 lb (0.46 kg) Network Module Weight, OC-12c/STM-4c Network .88 lb (0.4 kg) Module Weight, Gigabit Ethernet Network 1.04 lb ( 0.47 kg) Module Lucent Technologies A P - 2 6 365-575-925R1.5 Issue 1, April 2002...
Page 309: Appendix E: Preventing Electrostatic Discharge
• Avoid contact between printed circuit boards and clothing. A wrist or ankle strap only protects components from ESD voltages on the body; ESD voltages on clothing can still cause damage. Lucent Technologies 365-575-925R1.5 A P - 2 7 Issue 1, April 2002...
Page 310: Appendix F: Optistar™ Edgeswitch Warranty
No warranty is made that software will run uninterrupted or error free. Lucent Technologies A P - 2 8 365-575-925R1.5...
Page 311 MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. YOUR SOLE AND EXCLUSIVE REMEDY AND LUCENT'S SOLE OBLIGATION HEREUNDER, SHALL BE TO REPAIR, REPLACE, CREDIT OR REFUND AS SET FORTH ABOVE. Lucent Technologies 365-575-925R1.5 A P - 2 9 Issue 1, April 2002...
Page 312: Appendix G: Optistar™ Software License & Disclaimer Of Warranties
SOFTWARE. This license is limited to use in conjunction with the Lucent OptiStar EdgeSwitch, on a single processor at a time, or a single multi-processor unit designed to function as a single processor.
Page 313 (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 or subparagraphs (c) (1) and (2) of the Commercial Computer Software-Restricted Rights clause at 48 CFR 52.227-19, as applicable, Lucent Technologies Inc., 600 Mountain Ave., Murray Hill, NJ 07972.
Page 314 FOR SEPARATE WRITTEN AGREEMENTS BETWEEN LUCENT AND YOU, THIS AGREEMENT IS THE COMPLETE AND EXCLUSIVE STATEMENT OF THE RIGHTS AND LIABILITIES OF THE PARTIES WITH REGARD TO THE SOFTWARE. Lucent Technologies A P - 3 2 365-575-925R1.5 Issue 1, April 2002...
Page 315: Appendix H: Environmental And Regulatory Information
CSA C22.2 No. 60950-00, Third Edition, “Safety of Information Technology Equipment, Including Electrical Business Equipment” • EN 60950, “Safety of Information Technology Equipment” • IEC 60950, Third Edition, “Safety of Information Technology Equipment” Lucent Technologies 365-575-925R1.5 A P - 3 3 Issue 1, April 2002...
Page 316 Electromagnetic Immunity For Residential, Commercial and Light- Industrial Environments • EN 60950 (IEC950) Product Safety • EN 61000-3-2 Limits For Harmonic Current • EN 61000-3-3 Limitation Of Voltage Fluctuations and Flicker Lucent Technologies A P - 3 4 365-575-925R1.5 Issue 1, April 2002...
Page 317 Note: This equipment has been tested and found to comply with the Info-Communications Development Authority of Singapore (IDA) limits for a Class A digital device, pursuant to The IDA TS EMC Requirements for Telecommunication Equipment. VCCI Compliance Notice Lucent Technologies 365-575-925R1.5 A P - 3 5 Issue 1, April 2002...
Page 318: Appendix I: Cable Ordering
Cable Ordering Single Mode (8.3 Micron) Fiber The following fiber cabling is available for use with OptiStar EdgeSwitch WAN interface ports, including Gigabit Ethernet Network Module with Single Mode Fiber GBIC, OC-48c/STM-16c Network Module, or OC- 12c/STM-4c Network Module. Two fibers are required for connection to each port, one for transmit and one for receive;...
Page 319 MS1LC-LC-30 107735284 Simplex MiniCord MS1LC-LC-35 107735292 Simplex MiniCord MS1LC-LC-40 107735300 Simplex MiniCord MS1LC-LC-50 107735318 Simplex MiniCord MS1LC-LC-75 107735326 Simplex MiniCord MS1LC-LC-100 107735334 Simplex MiniCord MS2LC-LC-4 107735367 Duplex MiniCord Lucent Technologies 365-575-925R1.5 A P - 3 7 Issue 1, April 2002...
Page 320 Custom Multimode (62.5 Micron) Fiber The following fiber cabling is available for use with OptiStar EdgeSwitch LAN or SAN interface ports, including FCIP Network Module with Multimode Fiber GBIC or Gigabit Ethernet Network Module with Multimode Fiber GBIC. Two fibers are required for connection to each port, one for transmit and one for receive;...
Page 321 108913195 Duplex MiniCord ML2SC-SC-40 108913203 Duplex MiniCord ML2SC-SC-45 108913211 Duplex MiniCord ML2SC-SC-50 108913229 Duplex MiniCord ML2SC-SC-75 108913237 Duplex MiniCord ML2SC-SC-100 108913245 Duplex MiniCord LL1FC-SC-E/W 106473291 Simplex 9860A3 Custom Lucent Technologies 365-575-925R1.5 A P - 3 9 Issue 1, April 2002...
Page 322 Custom HSSDC and DB-9 Copper Cabling The following copper cabling is available for use with OptiStar EdgeSwitch LAN or SAN interface ports, including FCIP Network Module with HSSDC GBIC or DB-9 GBIC, or Gigabit Ethernet Network Module with HSSDC GBIC or DB-9 GBIC. One copper cable is required for connection to each port. The end of a copper cable intended to connect to the HSSDC GBIC must use an HSSDC connector.
Page 323 End 1 End 2 Length (meters) 848837092 DB-9 Male DB-9 Female Ethernet Cabling The following cabling is available for use to connect to the OptiStar EdgeSwitch 10/100 Ethernet management port: Length Product Code Comcode End 1 End 2 Cable Type...
Page 325: Index
Class 3 Port Statistics Parameters:Advanced. See System Show, 6-67 Parameters:Advanced. See System Clear Event Log, 6-7 Parameters:Advanced. See System Clear OptiStar EdgeSwitch Configuration, 5-60 Parameters:Advanced Clear System Errors, 6-83 AL_PA. See Private Addresses per Port CLI. See Command Line Interface. See Command ALTOV...
Page 326 Show, 6-73 Event Log FTP Server Clear, 6-7 Default Values, 4-51, 4-52 Show, 6-4, 6-69 Function Keys for CLI, 4-7 Event Log Severity Level, 6-6 Event Reporting Parameters, 6-3 Lucent Technologies INDEX 365-575-925R1.5 I N - 2 Issue 1, April 2002...
Page 327 OC-12c Network Module, 1-3, 1-11, 26 OC-48c Network Module, 1-3, 1-10, 26 Link Protocol Statistics Table Show, 6-72 Operational Information & Status, 5-2 Link Statistics Optical Power Budget, 2-6 Lucent Technologies 365-575-925R1.5 INDEX Issue 1, April 2002 I N - 3...
Page 328 OptiStar EdgeSwitch Definitions, 6-20 Save Current Configuration, 4-50 Show, 6-63, 6-64 OptiStar™ EdgeSwitch Port Diagnostics Table, 6-80 Configuration, 5-21 Port Login/Process Login Service Parameter Exchange. See PRLI Technical Specifications, 25 Ordering Information, 2-8 Port Mapping, 5-7, 5-31 OSPF Port Name...
Page 329 Switch Operating Mode Menu, 6-58 Set, 6-59 Show, 6-58 SAN Considerations, 2-7 Switching Module Zoning, 2-7 Parameters, 5-5 Save OptiStar EdgeSwitch Configuration, 4-50 Switching Port SDH Interfaces, 2-6 Default Parameters, 5-26 Sensor Information IP Address, 5-9 Show, 6-69 Parameters, 5-6...
Page 330 Troubleshooting, 8-2 How to Activate, 4-49 TXTHRESH How to Configure, 4-48 Set, 6-33 Joining Zoned Fabrics, 4-47 Merge, 4-45 Zoning Information Upload Firmware Show, 6-10, 6-61, 6-62, 6-63 Lucent Technologies INDEX 365-575-925R1.5 I N - 6 Issue 1, April 2002...
