Introduction to the Stinger Compact Remote ATM DSLAM

Stinger Compact Remote ATM DSLAM hardware

Stinger Compact Remote ATM DSLAM hardware
The Stinger Compact Remote ATM DSLAM unit, shown in Figure 1-3, consists of a
card-cage chassis in an integrated outdoor enclosure. The unit is designed for
installation in outdoor locations to bring DSL service close to customer locations. The
enclosure is pre-wired with protection blocks for the copper telecommunications
facilities, and provides an operating environment that can range between -40°F
(-40°C) and 114.8°F (+46°C). (For more environmental information, see "Operating
environment" on page D-9.) The card-cage chassis accommodates modular circuit
packs, a cooling unit, and a power supply.
Caution
!
colors, light gray, brown, and green. Because of the heat dissipation characteristics,
the maximum operating temperature for brown enclosures is 104°F (+40°C). Also,
green enclosures equipped with an IP2000 module must not contain more than two
sets of LIM/LPM modules in environments where ambient temperatures exceed
104°F (+40°C).
1-4
Stinger Compact Remote ATM DSLAM enclosures are produced in three
