Enclosure and Component
Installation

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Stinger CR enclosure Mounting Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Mounting the enclosure on a pole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Mounting the enclosure on a wiring cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Route and connect the fibers and ground cable inside the enclosure . . . . . . . . 3-15
Routing the cables out of the enclosure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Grounding the enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Inspecting and replacing the door gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Installation and replacement of Stinger CR components. . . . . . . . . . . . . . . . . . 3-20
Physical connections to the components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31
Turning on power to a Stinger CR ATM DSLAM unit . . . . . . . . . . . . . . . . . . . . 3-40
Status lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-41
What's next . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
Introduction
This section describes the hardware that is available for mounting the Stinger
Compact Remote in different locations. The installation process for the two most
common locations, pole mounting and cabinet mounting, are also described, along
with instructions for installing and replacing the components of the Stinger Compact
Remote.
Before you begin
To install the Stinger Compact Remote enclosure you must perform the tasks:
Locate all necessary hardware and tools at the installation site
Unpack the Stinger unit
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
3
3-1
3-1
3-2
3-7
3-13
3-15
3-16
3-18
3-19
3-20
3-31
3-40
3-41
3-47
3-1
