Table C-4.
P2
(LPM 1)
16T
16R
17T
17R
18T
18R
19T
19R
20T
20R
21T
21R
22T
22R
23T
23R
24T
24R
25T
25R
26T
26R
27T
27R
28T
28R
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Tip/Ring connections to protection blocks 2, 4, and 6 (Continued)
P4 P6 LPM
(LPM 2) (LPM 3) connector
64T 112T P2803
64R 112R P2803
65T 113T P2803
65R 113R P2803
66T 114T P2803
66R 114R P2803
67T 115T P2803
67R 115R P2803
68T 116T P2803
68R 116R P2803
69T 117T P2803
69R 117R P2803
70T 118T P2803
70R 118R P2803
71T 119T P2803
71R 119R P2803
72T 120T P2803
72R 120R P2803
73T 121T P2803
73R 121R P2803
74T 122T P2803
74R 122R P2803
75T 123T P2803
75R 123R P2803
76T 124T P2803
76R 124R P2803
Cables and Connectors
Cabling for the 48-port LPM with splitters
Pin No. LPM
connection
48 16T(POTS)
16 16R(POTS)
49 17T(POTS)
17 17R(POTS)
50 18T(POTS)
18 18R(POTS)
51 19T(POTS)
19 19R(POTS)
52 20T(POTS)
20 20R(POTS)
53 21T(POTS)
21 21R(POTS)
54 22T(POTS)
22 22R(POTS)
55 23T(POTS)
23 23R(POTS)
56 24T(POTS)
24 24R(POTS)
57 25T(POTS)
25 25R(POTS)
58 26T(POTS)
26 26R(POTS)
59 27T(POTS)
27 27R(POTS)
60 28T(POTS)
28 28R(POTS)
