Enclosure and Component Installation

Stinger CR enclosure Mounting hardware

Attach the appropriate Stinger CR mounting hardware to the outdoor
cross-connect cabinet, pedestal, pole, or rack.
Prepare cables and cable routes. (Drill pass-through holes, if required for cabinet
mounting, using the appropriate template, or make cabling provisions for pole
mounting.)
Mount the Stinger CR enclosure to the mounting hardware.
Route and connect cabling for telecommunication facilities and power to the
Stinger CR.
Warning
instructions in the Edge Access and Broadband Access Safety and Compliance Guide. See
Appendix D, "Safety-Related Electrical, Physical, and Environmental Information,"
for information specific to your product.

Stinger CR enclosure Mounting hardware

Depending on the local environment, the Stinger Compact Remote enclosure can be
mounted in the following ways:
On a standard telephone utility pole—The enclosure can be mounted on a
standard telephone utility pole in a center-mount or side-mount configuration.
On a concrete pad—A concrete pad can be poured, and the enclosure can be
mounted on the pad using the pedestal mount kit.
On an outdoor wiring cabinet—The rear or side of the enclosure can be mounted
to an outdoor wiring cabinet.
In an equipment rack—The enclosure can be installed in an equipment rack, in a
central office, or local equipment hut.
Several different mounting kits can be ordered with the hardware to support these
types of installations. These kits, with their Commodes, are identified and described
in Table 3-1.
Table 3-1. Stinger Compact Remote mounting hardware
Comcode
300715547
109579813
300716735
300719564
3-2
Before installing the Stinger hardware, be sure to read the safety
Description
Pole mount kit: center mount
(rear) or side mount
Pole mount kit: side mount only
Pedestal mount kit
Pedestal mount kit: cable and splice
hardware
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Includes
Pole mount brackets, center
(rear) mounting bracket,
hanger, lag bolts, cable cover,
and screws
Pole mount brackets, lag bolts,
cable cover, and screws
All components of 300719564
and 300719572
Splice cover, splice holder
bracket, cable cover for
pedestal mount, and screws
