Table C-4 Tip/Ring Connections To Protection Blocks 2, 4, And 6 - Lucent Technologies Stinger Compact Remote Getting Started Manual

Cables and Connectors
Cabling for the 48-port LPM with splitters
Table C-4.
P2
(LPM 1)
3T
3R
4T
4R
5T
5R
6T
6R
7T
7R
8T
8R
9T
9R
10T
10R
11T
11R
12T
12R
13T
13R
14T
14R
15T
15R
C-12
Tip/Ring connections to protection blocks 2, 4, and 6 (Continued)
P4 P6 LPM
(LPM 2) (LPM 3) connector
51T 99T P2803
51R 99R P2803
52T 100T P2803
52R 100R P2803
53T 101T P2803
53R 101R P2803
54T 102T P2803
54R 102R P2803
55T 103T P2803
55R 103R P2803
56T 104T P2803
56R 104R P2803
57T 105T P2803
57R 105R P2803
58T 106T P2803
58R 106R P2803
59T 107T P2803
59R 107R P2803
60T 108T P2803
60R 108R P2803
61T 109T P2803
61R 109R P2803
62T 110T P2803
62R 110R P2803
63T 111T P2803
63R 111R P2803
The Stinger® Compact Remote ATM DSLAM Getting Started Guide
Pin No. LPM
connection
35 3T(POTS)
3 3R(POTS)
36 4T(POTS)
4 4R(POTS)
37 5T(POTS)
5 5R(POTS)
38 6T(POTS)
6 6R(POTS)
39 7T(POTS)
7 7R(POTS)
40 8T(POTS)
8 8R(POTS)
41 9T(POTS)
9 9R(POTS)
42 10T(POTS)
10 10R(POTS)
43 11T(POTS)
11 11R(POTS)
44 12T(POTS)
12 12R(POTS)
45 13T(POTS)
13 13R(POTS)
46 14T(POTS)
14 14R(POTS)
47 15T(POTS)
15 15R(POTS)
