Barco Event Master E2 Lite User Manual page 90

EM GUI orientation
Input adjustment panel > Color Adjustment
This menu allows for color adjustments for each input.
Input adjustment panel > Contact Information
This menu allows for the user to enter contact information for easy identification.
90 R5909934 /00 E2 Lite and EC-40
• The RGB Contrast and Brightness settings are
adjustable.
- The Overall adjustment has a range of 50 to
150.
- The individual Red/Green/Blue adjustments
have a range of 25 to 150.
- The default setting for all of these properties is
100.
• Gamma is adjustable within a range of 0.31 to
3.29. The default setting is 1.0.
• Hue is adjustable within a range of –90 to +90
degrees. The default setting is 0 degrees.
• Saturation is adjustable within a range of 0 to 150.
The default setting is 100.
• Reset All changes all values to their default
settings.
