Barco Event Master E2 Lite User Manual page 144

EM GUI orientation
or
Select the background from the preview windows.
The layer is selected.
Image 6-55: Select background layer from Preview window
The background button will have a blue highlight when selected.
2. Click on the Adjust tab that is on the top of the adjustment area.
The background adjustment panel is displayed.
Background adjustment panel description
Background can either be either Still or Matte.
E2 Lite does not support Inputs as Backgrounds.
Background matte adjustment:
144 R5909934 /00 E2 Lite and EC-40
