General
User interface
User interface
Event Master Software
Event Master Console EC-40
The E2 Lite works only with the EMTS version 6.4.
Processing and latency
• 12 bits/color
• 36 bits/pixel
• 2 frame processing latency for progressive sources
PIP layers
Up to 32 PIP or Key overlay layers:
• 2K mode: 32x seamless PIP or Key overlay
• DL mode: 16x seamless PIP or Key overlay
• 4K mode: 8x seamless PIP or Key overlay
Background mixer
Each PGM screen destination has an unscaled seamless background mixer supporting the full resolution of
the destination.
• Matte color generator.
• Still store as background.
Destinations
The E2 Lite video processor has eight (8) Program Outputs configurable as single screens or tiled/blended
widescreens.
Program screens
The E2 Lite video processor has the following Program screens:
Max. number of HD (2K) outputs
Auxiliary Outputs
The E2 Lite video processor has user-definable Auxiliary Outputs.
Max. number of HD (2K) outputs
Multiviewer
Output resolution
HD (2K) output
Still stores
User-assigned still stores:
• Live capture
22 R5909934 /00 E2 Lite and EC-40
Details
• GUI based configuration and control application
• Cross platform (Mac/Windows)
Dedicated hardware panel specifically designed to
support Event Master processors
• 8x single screens
• 4x 2 output blended (2 output per blend) up to 8x
1 output blended
• 12x scaled AUX output
Max. number of Outputs
2x Multiviewer output
