Resize example:
Image 6-43
Match example:
Image 6-44
Transition
Image 6-45: Transition adjustments
1 Rate(frame) is the rate in frames at which transitions from Preview to Program take place.
2 Trans transitions Preview to Program according at the rate indicated in the rate box following the s-
curve pattern. The layer on Program does NOT fade in Preview at the same time. The layer on
Program appears in Preview when the transition is completed.
3 Cut transitions instantly the Preview to Program.
4 Transition type is a drop-down box that allows a choice of transition types. The available types are:
Linear, S-Curve, Logarithmic, and Exponential.
Image 6-46: Available transition types
EM GUI orientation
