E2 Lite Maintenance Actions; Maintenance Actions - Barco Event Master E2 Lite User Manual

Preventive maintenance actions

12.1 E2 Lite maintenance actions

MAINTENANCE TYPE C (perform every year)
The yearly maintenance actions, listed below, may be performed by the user in accordance with the
procedures described in the E2 Lite Maintenance chapter.
No. Maintenance action
1 Check battery valid date.
12.2 EC-40 maintenance actions
No preventive action is needed on this device.
222 R5909934 /00 E2 Lite and EC-40
Remarks
If the date is older than 4 years,
replace battery as a preventative
measure.
See Image 13-51 for the location
of the system battery.
Note: When a new battery is
installed, the user needs to place
a sticker with the date on the
inside of the metal plate (Bottom
Panel) that indicates when the
battery was last replaced. The
absence of sticker means the
battery has never been replaced.
In this case the S/N sticker can
be used for the reference date.
