1 Select All selects all Layers in Preview. It is equivalent to left clicking on all unselected layers on
Preview one at a time while Multiple Select is On.
2 Unselect All unselects all Layers in Preview. It is equivalent left clicking on all selected layers on
Preview one at a time while Multiple Select is On. Selection of anything allows the selected objects
on Destinations to be armed.
3 Multiple Select Off/On enables or disables the selection of more than one layer.
6.23 Programming Menu > Adjustment area
General
Situated on the right hand side of the screen is the Adjustment area. In this area users can configure Layers
and Sources and create User keys and Presets.
Description
There are several tabs in this area:
• Layers : Provides a list of the destinations. Under each destination a list of assigned layers and the
background is provided.
• User Keys : Provides a list of user keys. User keys contains all (or a portion) of the current layer's
attributes (such as border color, size, etc.). User Keys are not applicable for AUX Destination.
• Presets : List of Presets. Presets contains a group of Destination worth of information.
Note: Not all settings composing a layer is a layer setting, but a Source File setting. Be aware that for
desired result a USER KEY might have to be bound to a preset.
• Adjustment : Based on what is selected in the Preview or Program canvas area, this is the panel where
we are adjusting what is selected. For example if we select Layer1, we will be adjusting Layer1 settings.
• Source Adjustment: This panel is shown on the Adjust panel when a layer with a valid Source is selected.
At the bottom of the area, there is a set of buttons allowing execute transition actions on selected Destinations.
The following sections describe each panel of this area in detail:
• "Programming Menu > Adjustment area > Layer configuration", page 135
• "Programming Menu > Adjustment area > Background configuration", page 143
• "Programming Menu > Adjustment area > User Keys configuration", page 145
• "Programming Menu > Adjustment area > Presets configuration", page 148
• "Programming Menu > Adjustment area > Source adjustment", page 150
• "Programming Menu > Adjustment area > Global Transition Rate/Trans/Cut", page 151
6.24 Programming Menu > Adjustment area >
Layer configuration
General
In the Layer menu, users can manage the layer in the selected destination and update its attributes.
Layer configuration menu description
Layer configuration menu is accessed by clicking on the Layer tab.
EM GUI orientation
R5909934 /00 E2 Lite and EC-40 135
