System Setup

About this chapter
This chapter outlines procedures for setting up and configuring Event Master series processors.
CAUTION: Before starting to set up your Event Master series processor, please ensure that you are
familiar with front panel menus and Event Master Toolset Software.
Overview
•
Setup Prerequisites
•
System setup sequence
•
Power up and Status check
•
Return to factory default
•
Communication setup
•
Restoring the system
•
User preference setup
•
Saving the setup
•
Backing up the system
•
Configuration Menu > Initial Setup
•
Configuration Menu > Add Inputs
•
Configuration Menu > Add Outputs
•
Configuration Menu > Add Screen Destinations & Layers
•
Configuration Menu > Layer optimization
•
Configuration Menu > Add Aux Destinations
•
Configuration Menu > Add MVR Outputs
•
Programming Menu > Capture Stillstore from Inputs
•
Programming Menu > Select Thumbnails for Inputs
•
Programming Menu > Create Sources from Inputs
•
Programming Menu > Drop backgrounds into Screen Destinations
•
Programming Menu > Drop Sources, Layers into Screen Destinations & Sources into layers
•
Programming Menu > Drop Inputs to Aux Destinations
•
Programming Menu > Presets And User Keys
•
Programming Menu > Destination Transition
•
Multiviewer Menu > Drop Inputs and Destinations
