Remote Control Protocol
"Source":{"HPos":0,"VPos":0,"HSize":1920,"VSize":1080}, "Mask":
{ "Left":0.01, "Right":10.1, "Top":0.0,"Bottom":0.0},"PvwMode":1,"PgmMode":0,
"Freeze":0,"PgmZOrder":0,"PvwZOrder":0}]}
◦
id—Screen destination index.
◦
BGLyr—Background layer index, Last source index of background.
"id":0 affects the Background in Program. "id":1 affects the Background in Preview.
◦
Layers—Layer information.
◦
Window—Layer window size.
◦
Source—Source info and size.
◦
Mask—Crop the visible part of the layer.
◦
PvwMode—Set 1 if you want the content in preview. (Default)
◦
PgmMode—Set 1 if you want the content in program.
• Response:
- response: null
- success: (0=success, anything else is an error)
• Example:
-
{"params":{"id":0,"BGLyr":[{"id":0,"LastBGSourceIndex":0,"BGShowMatte":0,
"BGColor":[{"id":0,"Red":0,"Green":0,"Blue":0}]},{"id":1,
"LastBGSourceIndex":0,"BGShowMatte":0,"BGColor":[{"id":0,"Red":0,
"Green":0,"Blue":0}]}],"Layers":[{"id":0,"LastSrcIdx":0,
"Window":{"HPos":0,"VPos":0,"HSize":400,"VSize":300},
"Source":{"HPos":0,"VPos":0,"HSize":1920,"VSize":1080},
"Mask":{ "Left":0.01, "Right":10.1, "Top":0.0,"Bottom":0.0},
"PvwMode":1,"PgmMode":0,"Freeze":0,"PgmZOrder":0,"PvwZOrder":0}]},
"method":"changeContent", "id":"1234", "jsonrpc":"2.0"}.
freezeDestSource
• Definition:
- This API Freezes/Unfreezes the sources.
• Request:
- params: {"type": x, "id": y, "screengroup": z ,"mode": 0/1}
◦
type—type of source.
◦
0—Input source.
◦
1—Background source.
◦
2—ScreenDestination.
◦
3—AuxDestination.
◦
id—Index of the source.
- Screengroup—For future use. Always set to 0.
- Mode—0 : UnFreeze, 1 : Freeze.
• Response:
- response: null
- success: (0=success, anything else is an error)
• Example:
-
{"params": {"type": 0, "id": 0, "screengroup": 0 ,"mode": 1},
"method":"freezeDestSource", "id":"1234", "jsonrpc":"2.0"}
listStill
• Definition:
- This API lists all the stills with properties such as id, Name, H/V size, LockMode, StillState, PngState,
File size.
• Request:
- params: {}
• Response:
- response: Array of : [{"id":0,"Name":"StillStore1",
"LockMode":0,"HSize":{"Min":0,"Max":99999,"$t":1920},"VSize":{"Min":0,
"Max":99999,"$t":1080},"StillState":{"Min":0,"Max":4,"$t":3},"PngState":
