Noise Level
Dimensions
Weight
Power
Warranty
Environmental temperature 0–40 °C (32–104 °F)
Environmental humidity
A.2 Specifications of EC-40
EC-40 specifications
Connectivity
Dimensions (HxWxD)
Weight
A.3 Specifications of standard connections
Standard connection specifications
DisplayPort (DP)
DVI
• E2 Lite cards can only be used in E2 Lite. All Event Master cards can be
used in E2 Lite.
Max 52.9 dB avg. Fans at 100%.
Fan speed is software managed based on operating temperature. Reference
ISO 7779.
Height: 17.8 cm (7.0 in) - 4 RU Rackmount
Width: 43.2 cm (17.0 in) - without chassis handles, 48.3 cm (19 in) with
chassis handles attached
Depth: 56.9 cm (22.4 in) from front panel to rear panel, 62.2 cm (24.5 in)
overall
30.4 kg (67 lbs)
• Input power: 100-240 VAC 50/60Hz 826 Watt
• Dual-redundant, hot-swappable power supplies
3 years parts and labor
0–95% non-condensing
* USB connection from Event Master Toolset, from a control computer
* HDMI input for touchscreen monitor
244.34 x 511.56 x 610.05 mm / 9.62 x 20.14 x 24.02 inches
12.33 kg / 27.2 lbs
• Per DP 1.1a specification
• On DP connector
• Formats up to 2,560 × 1,600 at 60 Hz and 3,840 × 1,200 at 60 Hz (30 bits)
• 4K/UHD supported:
- 3,840 × 2,160/23.98/24/25/29.97/30 via 1x DP, 2x DP (L and R half), or
4x DP (quadrants)
- 3,840 × 2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096 × 2,160/23.98/24/25/29.97/30 via 1x DP, 2x DP (L and R half) or 4x
DP (quadrants)
- 4,096 × 2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096 × 2,400/23.98/24/25/29.97/30/50/59.94/60 via 2x DP (L and R half)
or 4x DP (quadrants)
• EDID version 1.3 compatible
• HDCP version 1.4 compatible
• Per DVI 1.0 specification
• DVI Digital video on DVI-I connector
• All single-link DVI formats up to 165 MHz
• All dual-link DVI formats up to 330 MHz
• Maximum H Active: 4,096; Maximum V Active: 3,072
Specifications
